Fuel Density Meter FD-5110 New

Achieves high accurate mass flow measurement with a new fuel density meter and volumetric flow detector

By connecting with the FM-3100 Digital Flow Meter, the FD-5110 Fuel Density Meter can measure temperature and density data in real time. In addition, the FP series Volumetric Flow Detectors with wide range ability and the FD-5110 are the best choice for achieving the accurate mass flow measurement.

Features

1.Achieves low pressure loss and high accuracy in small flow rate

With the use of the FP series volumetric flow detector, the pressure loss of 20 kPa or less (at 60 L/h) is achieved. The detector can be installed with the minimum pressure fluctuations of the flow path. Compared to the FZ-2200A, the measurement accuracy in the low flow range is improved. Thus, it is ideal for starting test.

2.Compact And Light Weight System

Compact and space-saving design. (50 % size reduction compared to the existing model.)



Instantaneous massflow measurement at starting engine






3.Applicable To Various Volumetric Flow Detectors

Achieve various mass flow measurements selecting a volumetric flow detector from small to large flow.

4.Makes the procedures in mode and performance tests simple

Depending on the area and installation location, various factors such as fuel type and density are varied. Ono Sokki’s mass flow measurement system does not require the troublesome density data input etc. with real-time density measurement and mass conversion.



System configuration

In combination with the FP-5000 series Volumetric Flow Detector



Specifications

Measurement items Density, temperature
Usable liquid Gasoline/ kerosene/ diesel oil/ heavy oil A/ engine oil/ common petroleum hydraulic oil/ methanol/ ethanol/ mixture of alcohol and gasoline/ brake oil, etc.
Measurement range 0.5000 to 2.0000 g/cm 3
Minimum resolution 0.0001 g/cm3
Measurement accuracyDensity
Temperature
±0.0010 g/cm3(Light oil, Cleansol HS at 20 ℃)
±0.1 ℃
Operating temperature range +10 to+65 ℃ (liquid temperature)
−10 to+50 ℃ (ambient temperature)
Dimension 60 × 60 × 176 mm
Weight Approx. 1.5 kg
Power DC5 V 60 mA (supplied by FM-3100)
Conforming standard EMC Directive 2014/30/EU Standard EN61326-1
RoHS Directive 2011/65/EU Standard EN IEC 63000
Inlet/outlet port Rc 3/8
Accessory Instruction manual
Cable Optional FD-0011(5 m), FD-0012(10 m), FD-0013(15 m)
Applicable flow meter Digital flow meter FM-3100 / FM-0311A + FM-0312

Option

modelname
FM-0312FD additional connectorFor density input connection
EH-0711Mounting fixtureFor FD-5110
FD-0011Density signal cable 5 mFor connecting with FM-3100(FM-0311A + FM-0312)
FD-0012Density signal cable 10 mFor connecting with FM-3100(FM-0311A + FM-0312)
FD-0013Density signal cable 15 mFor connecting with FM-3100(FM-0311A + FM-0312)

On-board Volumetric Flow Detector FP-4135

The FP-4135 On-Board Volumetric Flow Detector is the high-precision positive displacement flow detector to measure the fuel flow rate of liquids such as gasoline, light oil and kerosene combined with the Ono Sokki DF-2200 On-Board Flow Meter or the FM series Digital Flow meter.
Because the flow rate range is as wide as 0.1 to 200 L/h (measurement range ratio 2000 : 1 ), it can measure from very low flow rate in an idling state to large amount of flow rate in a high-load state when a fuel with a low heating value such as alcohol is used.
Also, since the flow detecting part is compact and its operating temperature range is -30 to +100°C, it can be installed inside an engine room to measure the actual driving fuel efficiency.

Features

1. Improved vibration resistance & environment resistance

The detection part and the signal processing part are separated in consideration of temperature changes in the engine room and use in environmental tests. It supports vibration of about 3 G and environmental temperature of -30 °C to +100 °C, and has excellent vibration resistance and environmental resistance.

Vibration test
Temperature test
   : 27.3 m/s2
   : -30 °C to +100 °C

接続例
接続配置例


2. Ultra compact filter, built-in temperature sensor

Downsized filter achieves 70% reduction in volume. (Compared to the FP-2140H)
An ultra compact filter is equipped as standard inside to protect the detector from impurities contained in the fuel.
The filter is removable and easy to maintaine every test. A built-in temperature sensor is also equpped as standard.

Temperature measurement range
Temperature accuracy
   : -30 °C to +100 °C
   : Class A

超小型フィルタ
背面イメージ


3. One-touch connection with SAE joint (option)

By attaching a joint to actual vehicle (option) to the top of the detector, you can easily connect to the fuel hose of the vehicle. It prevents fuel from leaking in the engine compartment.

SAE J2044 joint

Screwed type joint (Rc 1/4)

ねじ込み継手(Rc1/4)
FP-4135


4. Wide measurement rane, low pressure loss, supporting alcohol as standard

Measurement range: 0.1 to 200 L/h

Low pressure loss
Measurable liquid
   : Adapting a magnetic encoder enables to reduce the weight of detector
   : Alcohol as standard, a wet part with excellent chemical resistance used




FP-4135
DC10~28V
DC10~28V

System configuration

System configuration

Video (Easy flow rate measurement with SAE joint)



Case study

Repeated measurement of section fuel consumption during actual driving

Taking advantage of the compact and lightweight speedometer, the LC-8300A, mount it on a motorcycle to measure mean velocity, fuel consumption, and fuel efficiency every 10 m from the start. From the results, the fuel efficiency will be evaluated.



Specification

Measurable liquid Gasoline, light oil, kerosene, class-A heavy oil, engine oil, petroleum-based general hydraulic oil, methanol, ethanol, mixture of alcohol and gasoline, and brake oil
*Please note that the detector might not be used in the depositing condition.
*Alcohol is measurable as standard.
Measurement rangeFlow rate0.1 to 200 L/h
Temperature-30 to 100 °C
AccuracyFlow ratewithin ± 0.2 % of reading(measurement condition: 20 °C, 50% RH, Cleansol HS)
TemperatureClass A
Pressure loss 4 kPa or less at 60 L/h (gasoline)
Operating temperature range Flow detecting part:-30 to 100 °C (environment temperature, liquid temperature, with no condensation)
Signal processing part:-30 to 70 °C (environment temperature)
Inlet/Outlet port Rc1/4
Operating maximum pressure 8 Mpa
Vibration resistance (conducted) Acceleration rms value: 27.3 m/s2
10 to 1000 Hz random vibration
1 hour for each direction of each 3 axis
Weight Flow detecting part: approx.2.0 kg
Signal processing part: approx.0.4 kg
Power source Power is supplied from the DF-2200 On-Board Flow Meter or the FM Series Digital Flow Meter
Accessory Instruction manual
Applicable cable Option: FP-0015(5m), FP-0016(10m), FP-0017(20m)
Applicable detector/flow meter DF-2200 On-Board Flow Meter
FM-3100 Digital Flow Meter+ FP-0311 measurement module for FP series
FM-2500A Digital Flow Meter + DF-0400A measurement module for FP series
FM-1500 Digital Flow Meter + DF-0400A measurement module for FP series

*When using it on an engine bench, it is possible to extend the maintenance interval for filter cleaning by installing an external filter on the primary side of the flow meter.
(For filter, please contact us to quote.)

Option

Model nameProduct nameRemarks
FP-0015Flow signal cabsignal cable, 5 mConnection cable for FM/DF series
FP-0016Flow signal cable, 10 m
FP-0017Flow signal cable, 20 m
FP-0025Temperature signal cable, 5 mConnection cable for FM/DF series
FP-0026Temperature signal cable, 10 m
FP-0027Temperature signal cable, 20 m
FP-0035Pressure signal cable, 5 mConnection cable for FM/DF series
FP-0036Pressure signal cable, 10 m
FP-0037Pressure signal cable, 20 m
FP-0411For FP-4135: Inlet/Outlet filter setInlet/Outlet filter and O-ring set
FP-0412for FP-4135: O-ring set for filter maintenanceO-ring set for filter maintenance
FP-0413For FP-4135: O-ring set for filter maintenanceO-ring set for filter maintenance (perfluoro type)
FP-0414For FP-4135: Temperature sensorStandard, class A
FP-0415For FP-4135: Additional pressure sensor setPressure measurement: 0 to 980 kPa, F.S.±0.5 %
FP-0416For FP-4135: Pressure sensorPressure measurement: 0 to 980 kPa, F.S.±0.5 %
FP-0417For FP-4135: Top cover block (side port)Inlet/outlet Rc1/4 port (side)
FP-0418For FP-4135: Front mounting fixture 1Front mounting fixture
FP-0419For FP-4135: Rear mounting fixture 2Rear mounting fixture 2 (not suitable for on-board)
FP-0420For FP-4135: Mounting fixture for signal processing part (M6)MFor M6 screw hole
FP-0421For FP-4135: Φ6 mmSAE (side) blockΦ6.3 Max. operating pressure 500 kPa
FP-0422For FP-4135: Φ8 mmSAE (side) blockΦ8 Max. operating pressure 500 kPa
FP-0423For FP-4135: Φ6 mmSAE (top) blockΦ6.3 Max. operating pressure 500 kPa
FP-0424For FP-4135: Φ8 mmSAE (top) blockΦ8 Max. operating pressure 500 kPa



Flow detector with pressure loss compensation function
FP-213S / FP-2140S

FP-213S                                       FP-2140S

he Volumetric Flow Detector FP-213S, FP-2140S are volumetric flow detectors, used in combination with the Digital Flow Meter FM/DF series, for precision measurement of fuel flow such as gasoline, light oil and kerosene.
They are suitable for those who want to evaluate the engine performance by measuring the minute flow rate of a small engine and making the fuel supply pressure as close as possible to the actual vehicle state.

Features

1. Low pressure loss compensation function (10 Pa or less)



They provide the pressure loss compensation function that compensates the pressure loss by servo-driving the motor coupled with the rotary encoder to keep the free piston at the neutral position (zero difference of pressure).

principle

The position of the free piston is always detected by the eddy current sensor. The low pressure of 10 Pa or less and the highly accurate flow rate meassurement are available.



2. Wide range ability

FP-213S Measurement range: 0.06 to 60 L/h
Wide range ability: 1 : 1000
FP-2140S Measurement range: 0.05 to 200 L/h
Wide range ability: 1 : 4000

3. High accuracy: FP-2140S (within ±0.2 % of reading)

Within ±0.2 % of reading over the entire flow range of 0.05 to 200 L/h



System configuration

*Please contact us if you would like to add temperature sensors, pressure sensors, and density meters.



Specifications

 FP-213SFP-2140S
Measurement itemFlow rate
TemperatureOptionOption
PressureOptionOption
Detection methodVolumetric flow rate detection (Piston method)
Usable liquidStandardGasoline, light oil, kerosene, general petroeum-based hydraulic oil (**2)
Alcohol applicable
(option)
Gasoline, light oil, kerosene, general petroeum-based hydraulic oil (**2)
methanol, ethanol or mixure of alcohol and gasoline
Measurement rangeFlow rate0.06 to 60 L/h
(1 to 1000 mL/min, 0.02 to 16.7 mL/s)
0.05 to 200 L/h
(0.83 to 3333 mL/min, 0.01 to 55.5 mL/s)
TemperatureOptionOption
PressureOptionOption
AccuracyFlow rateWithin ±0.5 % of reading
(over the entire range 0.06 to 60 L/h)
Within ±0.2 % of reading
(over the entire range 0.05 to 200 L/h)
TemperatureOptionOption
PressureOptionOption
Pressure loss0.01 kPa or less
(excluding pressure loss at filter section)
Minimum resolution0.01 mL
Maximum operating pressure980 kPa
Operating temperature:0 to +60 °C
FilterEH-106A provided as standardEH-1050 provided as standard
WeightApprox. 2.5 kg (including filter)Approx. 9 kg (including filter)
AccessoriesLine filter EH-106A, Instruction manual, mounting bracket, screw (M5×4)Line filter EH-1050, Instruction manual, mounting bracket
Signal cablePleaes refer to the option.
Applicable detectorsDigital Flow Meter
DF-2200
FM-3100 / FM-0311A

*1: If the inlet pressure is lower than the pressure low and if the outlet is open to the atmosphere, the instantaneous flow rate may be varied.
*2: In the case of high viscosity fluid, pressure loss compensation may become insufficient in the high flow areas.

Option

Model nameProduct nameRemarks
FM-0312FD additional connectorFor density input connection
FP-0011Flow signal cable, 5 mFor FP-213S  FM/DF series flow meter
FP-0012Flow signal cable, 10 m
FP-0014Flow signal cable, 20 m
FP-0015Flow signal cable, 5 mFor FP-2140S  FM/DF series flow meter
FP-0016Flow signal cable, 10 m
FP-0017Flow signal cable, 20 m
FP-0025Temperature signal cable, 5 mConnection cable for FM/DF series
FP-0026Temperature signal cable, 10 m
FP-0027Temperature signal cable, 20 m
FP-0035Pressure signal cable, 5 mConnection cable for FM/DF series
FP-0036Pressure signal cable, 10 m
FP-0037Pressure signal cable, 20 m

Volumetric Flow Detectors FP-5000 series New

FP-5000 series

Achieves accurate and wide range of mass flow measurement from small to large flow rate

In engine evaluations such as emission mode tests and transient tests for performance evaluation, the evaluation methods have been shifting from steady-state tests to transient tests. In the evaluation of fuel consumption, the requirement for evaluating the fuel consumption characteristics in transient duration has been increasing as well as the total fuel consumption for each mode. The FP-5000 series has achieved high pulse resolution and wide measurement range. It enables to detect changes in the flow rate effectively and responsively, and measure large flow rate. It can be used when the flow rate increases, such as when measuring alcohol fuel.

Features



1.Measuring even small amount of changes in the flow rate

Achieves 0.0005 mL/pulse resolution (when using FP-5130 series, up to 20 times of the existing models)


Instantaneous massflow measurement at starting engine

Integrated mass flow rate test during fuel injection by an injector



 Installation method of FP-5000 series Flow Detector

Installation method of FP-5000 series Flow Detector




2. Wide detector lineup supports from small to large flow rate

There are a wide range of flow detectors, which can be used for various applications from idling to WOT with a single detector.








3. Compact and space-saved design

A filter, the Volumetric Flow Detectors FP-5000 series, a flow detector, and a temperature/pressure sensor unit can be connected together, and achieved space saving.



4. Applicable to alcohol mixed fuel as standard

The flow detector is applicable to alcohol as standard.
The detector can be used without modification in the fuel flow measurement of engines that often use alcohol fuel.

System configuration

Figure of FP-5000 system configuration



Specifications

Standard typeSmall flow rate typeMedium flow rate typeLarge flow rate type
SeriesFP-5130 seriesFP-5140 seriesFP-5150 series
 FP-5130 seriesFP-5140 seriesFP-5150 series

Usable liquidGasoline, light oil, kerosene, alcohol, biofuel and general petroleum-based hydraulic oi (*1)
Measurement rangeFlow rateFP-5131/5132 : 0.05 to 60 L/h
FP-5133/5134 : 0.05 to 108 L/h
(*2)
FP-5141/5142 : 0.3 to 300 L/h
FP-5143/5144 : 0.3 to 600 L/h
FP-5151/5152 : 1 to 1440 L/h
AccuracyFlow rateWithin ±0.0009 L/h
(0.05 to 0.18 L/h )
Within ±0. 5 % of reading
(0.18 to 108 L/h)
Within ±0.2% of readingWithin ±0. 5 % of reading
Pressure loss8 kPa or less
(at 40  L/h <gasoline>)
2 kPa or less
(at 60 L/h <gasoline>)
7.5 kPa or less
(at 500  L/h <light oil>)
Operating temperatureliquid0 to +65 °C0 to +65 °C0 to +65 °C
ambient0 to +65 °C0 to +65 °C0 to +65 °C
Inlet/ outlet portSizeIN: Rc3/8 (*3)
OUT: Rc3/8 (*3)
IN: Rc3/8 (*3)
OUT: Rc3/8(*3)
IN: Rc1/2
OUT: Rc1/2
Maximum operating pressure1 MPa1 MPa3.4 Mpa
Temperature/ pressure sensor unitEH-0830EH-0830EH-0850
Measurement rangeTemperature0 to +100 °C0 to +100 °C0 to +100 °C
Pressure0 to 1 MPa0 to 1 MPa0 to 1 MPa
AccuracyTemperaturePT100 Ω A classPT100 Ω A classPT100 Ω A class
Pressure±0.25 % F.S±0.25 % F.S±0.25 % F.S
Weight Approx. 3.5 kgApprox. 5.0 kgApprox. 13.5 kg
Accessary Instruction manual, line filter(EH-1130 or EH-1150), mounting bracket (Appropriate stand bracket for FP-5130/5140 series is supplied according to the selection of options.)
Cable Optional: FP-0015(5m), FP-0016(10m), FP-0017(20m)
Applicable flow meterDigital flow meters:
FM-2500A/ DF-0400A (*not applicable to FP-5132, 5134, 5142, 5144 and 5152)
DF-2200(*not applicable to FP-5132, 5134, 5142, 5144, 5151 and 5152)
FM-3100/ FM-0311A
Filter/ Element
Alcohol applicableFilterEH-1130EH-1130EH-1150
ElementEH-0031AEH-0031EH-0051A

Please take note that the instantaneous flow rate may be varied;
1.if the inlet pressure is lower than the pressure loss.
2.if the outlet of the detector is open to the atmosphere.
(*1) Please contact to your nearest distributor.
(*2) Made-to order for the measurement range from 0.02 L/h. Please contact to your nearest distributor.
(*3) Option joint (SAE joint) is available. Please contact to your nearest distributor.

Option

ModelProduct nameContents
FM-0312FD additional connectorFor density input connection
FP-0015Signal cable for flow rate 5 mConnection cable for FM/DF series
FP-0016Signal cable for flow rate 10 m
FP-0017Signal cable for flow rate 20 m
FP-0025Temperature signal cable, 5 mConnection cable for FM/DF series
FP-0026Temperature signal cable, 10 m
FP-0027Temperature signal cable, 20 m
FP-0035Pressure signal cable, 5 mConnection cable for FM/DF series
FP-0036Pressure signal cable, 10 m
FP-0037Pressure signal cable, 20 m
FD-0011Density signal cable, 5 mConnection cable for FM series
FD-0012Density signal cable, 10 m
FD-0013Density signal cable, 15 m
EH-0830Temperature/pressure sensor units for FP-513X, FP-514XFor FP-513x, FP-514x
EH-0830 is a combination of EH-0081 and EH-0082
EH-0850Temperature/pressure sensor units for FP-515XFor FP-515x
EH-0731Mounting bracket for FP513x (single unit)1UNIT: Flow detector including line filter
EH-0732Mounting bracket for FP513x (2 units)2UNIT: Flow detector + Density meter or Temperature/pressure sensor unit
EH-0733Mounting bracket for FP513x (3 units)  3UNIT: Flow detector + Density meter + Temperature/pressure sensor unit
EH-0741Mounting bracket for FP514x (single unit)1UNIT : Flow detector including line filter
EH-0742Mounting bracket for FP514x (2 units)2UNIT: Flow detector + Density meter or Temperature/pressure sensor unit
EH-0743Mounting bracket for FP514x (3 units)  3UNIT: Flow detector + Density meter + Temperature/pressure sensor unit
EH-0730AStand bracket for FP513x/514xWhen using the stand, use at vibration of 9. 8 m/s2 or less.

Motor torque detector MT series

High-performance motors including ultra-precision motors are used in various fields. Many different types of motors are used in versatile applications, such as ultra-high-speed motors used in home appliances, low-speed motors used in OA equipment and AV equipment, and ultrasonic motors

Ono Sokki provides wide variety types of torque detectors as the MT-series. You can select to meet requirements, including measurements for high speed rotation motor, for large capacity motor, for torque ripple, and for cogging torque.

Further, the MT series with the compact high-rigidity torque detector RH series have been added.
The RH type torque detector (10 Nm / 20 Nm) is a torque detector that achieves high accuracy (± 0.05% F.S.) and high rigidity (4.5 times that of our existing models). It enables to measure torque fluctuations of motors in a higher frequency range with higher accuracy.

* TS-8700 Torque Station Pro is required for motor characteristics measurement separately in addition to the MT series detector.

Overview Specification

MT series Common Specifications
Torque detection methodMT-8M :Electromagnetic gear type phase difference method
MT-8 T :Electromagnetic induction phase difference method
MT-8 R :Strain gauge detection method
Bearing methodBall bearing type
Torque measurement accuracy

±0.2 %/F.S.
±0.05 %/F.S. (MT-8R)
±0.1 %/F.S. (some models of MT-8T(with TH detector))
**: When combined with TS-8700/7700B, after N-0 compensation. 1 second averaged value.
The influences below are excluded.
- fluctuation components generated from the system components
- resonance components including the target

Motor power supplyNot included motor power supply
Power requirementMT-8M: AC100 to 240 V ±10% 50/60Hz
MT-8T: AC100 V ±10% 50/60Hz
MT-8R: AC100 to 240 V ±10% 50/60Hz
Power consumptionMT-8M  : small capacity: approx. 20 VA or less / large capacity: approx. 38 VA or less
MT-8T  : small capacity: approx. 6 VA or less / large capacity: approx. 7 VA or less
MT-8R  : approx. 44 VA or less
Isolation resistance10 MΩ or more (rated voltage: DC 500 V)
Withstand voltageAC 1500 V for 1 minutes
Temperature/humidity

Operating temperature range: +0 to +40 ℃
Operating humidity range: +30 to +80 %RH(with no condensation)
Storage temperature range: −10 to +50 ℃
Storage humidity range: +30 to +80 %RH(with no condensation)

Altitude condition etc.

Pollution degree: 2
Max. altitude: 2000 m(only for MT-8T/R)
Max. altitude:1000 m(MT-8M)
With no condensation, with no corrosive gas

Conforming standard

RoHS Directive, CE marking, FCC (CE marking(FCC : MT-8T(only for MT series with TH))

CE markingLow voltage Directive:2014/35/EU EN61010-1
EMC Directive:2014/30/EU EN61326-1 class 1 Industrial environment
RoHS Directive:2011/65/EU EN IEC 63000
FCCCRF47 Part15 Subpart B class A
Braking abilityCan be used within the shaded area in the figure below


* MT-84/85 series can be used within the upper range and within the braking capability W.
Braking capability W=Torque N·m × Rotation speed r/min × 0.10472

MT-82 M/T/R Torque ripple/cogging torque measurement

MT-82 M/T/R Torque ripple/cogging torque measurement


  • This model is suitable for torque ripple measurement in the state of motor excitation, and cogging torque measurement in the state of non-excitation motor.
    Control and measurement are performed at intervals below.
  • MT-82M: 0.5 to 5 r/min
    MT-82T: 2 to 15 r/min (excluding some models)
Measurement itemTorque, rotation speed, rotation angle*, current*, voltage* (*:option)
WeightVaries depending on the model.

*It may be affected by the fluctuation component caused by the equipment component and the resonance component including the target to be tested.
Details will be decided after the meeting.

SeriesID codeTorque
(N(m)
Rotation speed range
(r/min)
Torque measurement accuracy
(%/FS)
Standard type with MD/SS (successor of
MT-6200B series)
82M210.0020.5to5±0.2
82M510.0050.5to5±0.2
82M120.010.5to5±0.2
82M220.020.5to5±0.2
82M520.050.5to5±0.2
82M130.10.5to5±0.2
82M230.20.5to5±0.2
82M530.50.5to5±0.2
82M1410.5to5±0.2
82M2420.5to5±0.2
82M5450.5to5±0.2
82M15100.5to5±0.2
82M25200.5to5±0.2
High performance type with TH (successor of
MT-6200B series)
82T520.052to15±0.2
82T130.12to15±0.2
82T230.22to15±0.2
82T530.52to15±0.2
82T1412to15±0.2
82T2422to15±0.1
82T5452to15±0.1
82T15100.5to5±0.1
82T25200.5to5±0.1
High accuracy type with RH82R15100.5to5±0.05
82R25200.5to5±0.05

MT-84 M/T/R TN/TI characteristics measurement with hysteresis brake

MT-84 M/T/R Hysteresis brake type


  • Suitable for measurement of high speed rotating motor.
  • Rotation speed of the motor and torque characteristics are automatically measured in combination with the TS-8700 Torque Station Pro.
  • Controls torque and rotation speed, can be used for AC motor measurement, DC motor measurement.
Measurement itemTorque, rotation speed, current*, voltage*(*:option)
WeightVaries depending on the model.

*Cannot be measured in no-load condition due to the idling torque on the brake.
*It may be affected by the fluctuation component caused by the equipment component and the resonance component including the target to be tested.
   Details will be decided after the meeting.

SeriesID codeTorque
(N(m)
Braking capability
(W)
Rotation speed range
(r/min)
Torque measurement accuracy
(%/FS)
Standard type with MD/SS (successor of
MT-6200B series)
84M220.025100 to 20,000±0.2
84M520.058100 to 20,000±0.2
84M130.112100 to 20,000±0.2
84M230.223100 to 15,000±0.2
84M530.575100 to 12,000±0.2
84M14175100 to 12,000±0.2
84M242160100 to 10,000±0.2
84M545200100 to 10,000±0.2
84M1510350100 to 7,000±0.2
84M2520600100 to 7,000±0.2
High performance type with TH (successor of
MT-6200B series)
84T220.025100 to 9,000±0.2
84T520.058100 to 11,000±0.2
84T130.112100 to 20,000±0.2
84T230.223100 to 15,000±0.2
84T530.575100 to 12,000±0.2
84T14175100 to 12,000±0.2
84T242160100 to 10,000±0.1
84T545200100 to 10,000±0.1
84T1510350100 to 7,000±0.1
84T2520600100 to 7,000±0.1
High accuracy type with RH84R1510350100 to 7,000±0.05
84R2520600100 to 7,000±0.05

*Cannot be measured in no-load condition due to the idling torque on the brake.

MT-85 M/T/R TN/TI characteristics measurement with powder brake

MT-85 M/T/R Powder brake type


  • Suitable for measurement of large capacity and low speed rotating motor, such as a motor with gear.
  • Rotation speed of the motor and torque characteristics are automatically measured in combination with the TS-8700 Torque Station Pro.
Measurement itemTorque, rotation speed, current*, voltage*(*:option)
WeightVaries depending on the model.

*Cannot be measured in no-load condition due to the idling torque on the brake.
*It may be affected by the fluctuation component caused by the equipment component and the resonance component including the target to be tested.
 Details will be decided after the meeting.
*Please consult us for a detector for large torque capacity (made-to-order) .



SeriesID codeTorque
(N(m)
Braking capability
(W)
Rotation speed range
(r/min)
Torque measurement accuracy
%/FS
Standard type with SS (successor of MT- 6500B series)85M141205to1,800±0.2
85M242505to1,800±0.2
85M5451305to1,800±0.2
85M15103205to1,800±0.2
85M25204505to1,800±0.2
High performance type with TH
(successor of MT-6500B series)
85T141205to1,800±0.1
85T242505to1,800±0.1
85T5451305to1,800±0.1
85T15103205to1,800±0.1
85T25204505to1,800±0.1
High accuracy type with RH85R15103205to1,800±0.05
85R25204505to1,800±0.05

Option (ordered with ID cord)

/B1 XYZ base for small capacity



Base to attach a target with XYZ stage (/X1)and V block (/V1). Used for small capacity torque measurement, desktop type.


Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14



/B2 L-shaped base for small capacity



Base to attach a target with L-shaped jig (/L1).
Used for small capacity torque measurement. Desktop type.

Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14




/B3a Stand with XYZ stage and casters for medium capacity



Base to attach a target with XYZ stage +V block (/V2 or /V3) .Used for medium capacity torque measurement. Stand type.


Table surface :200 mm
X (Rotation axis perpendicular horizontal direction) :±10 mm
Y (Rotation axis horizontal back

    and forth direction) :±20 mm
Z (Vertical direction) : 70 mm
Load capacity : 5 kg

Applicable MT series
82T24 to 82T25, 82R15, 82R25
82M14 to 82M25,84R15, 84R25
84T24 to 84T15, 85R15, 85R25
84M24 to 84M15
85T14 to 85T25
85M14 to 85M25



/B3b Stand with XYZ stage and casters for small capacity +Center height adjustment plate+blinding plate



Stand to measure small capacity torque with V block (/V2 or /V3). MT series torque detector will be mounted on the stand . Specification of stand(XYZ stage: Same to /B3a.

Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14



/B4 Large stand with casters for medium & large capacity



Stand to measure medium and large capacity torque with slide base(/S3)and L-shaped jig(/L2). MT series torque detector will be mounted on the stand.


Applicable MT series
82T24 to 82T25, 82R15, 82R25
82M14 to 82M25, 84R15, 84R25
84T24 to 84T25, 85R15, 85R25
84M24 to 84M25
85T14 to 85T25
85M14 to 85M25




/X1 XYZ stage for small capacity



XYZ stage to support measurement of small torque capacity. Desktop type.

Table surface: 80 mm
X(Rotation axis perpendicular horizontal direction):±12.5 mm
Y(Rotation axis horizontal back

    and forth direction) :±12.5 mm
Z(Vertical directions) : 45 mm
Load capacity : 3 kg

Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14




/S3 L-shaped jig slide base for medium & large capacity



Slide base used for the measurement using L-shaped jig (/L2) on the large stand with casters


Sliding amount of L-shaped metal fixture : 330 mm (Length from end to end. Actual sliding amount depends on the L-shaped metal fixture to be placed.)




/V1 V block A for small capacity Φ30 to 60



V block used for the measurement of small capacity torque using XYZ stage (/X1) . Desktop type.


Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14



/V2 V block B for medium capacity Φ60 to 120



V block used for the torque measurement using a stand with XYZ stage (/X1) and casters (/B3a or /B3b).
Outer diameter range of a target:Φ60 to 120


Applicable MT series
Same as /B3a and /B3b



/V3 V block C for medium capacity Φ100 to 150



V block used for the torque measurement using a stand with XYZ stage (/X1) and casters (/B3a or /B3b).
Outer diameter range of a target:Φ100 to 150


Applicable MT series
Same as /B3a and /B3b




/L1 L-shaped jig for small capacity



For small capacityz
Used with L-shaped base (/B2). Desktop type. The target is attached via the surface plate provided as standard. Helps reproducible centering, when testing the same model many times etc.
*Processing to a surface plate by Ono Sokki: offered for a fee Please contact your nearest distributor for more details.
L-shaped inner diameter of in-low section: Φ50H7
Center height: 130 mm


Applicable MT series
82T52 to 82T14
82M21 to 82M53
84T22 to 84T14
84M22 to 84M14



/L2 L-shaped jig for medium capacity



For medium & large capacity

Used with Large stand with casters (/B4) to measure medium or large capacity torque. The target is attached via the surface plate provided as standard. Helps reproducible centering, when testing the same model many times etc.
*Processing to a surface plate by Ono Sokki: offered for a fee Please contact your nearest distributor for more details
L-shaped inner diameter of in-low section: Φ62H7
Center height: 140 mm


Applicable MT series
82T24 to 82T25, 82R15, 82R25
82M14 to 82M25, 84R15, 84R25
84T24 to 84T25, 85R15, 85R25
84M24 to 84M25
85T14 to 85T25
85M14 to 85M25




/E1 Encoder

Detectors for torque ripple and cogging torque (except for some torque detectors). Rotation angle measurement and angle sampling can be performed in 0.1 degree steps.

* Rotation speed range : from lower limit speed of the MT detector to 5 r / min If the resonance will be occurred in the rotation speed range, it may not measure the angle (angle sample). In that case, the rotation speed should be changed.




/L3 Cable length 3 m

Cable for between MT and TS
Torque signal cable: 3 m
Rotation signal cable : 3 m
Control amplifier cable: 3 m
AC power cable for MT: 1.9 m



/L5 Cable length 5 m

Cable for between MT and TS
Torque signal cable : 5 m
Rotation signal cable : 5 m
Control amplifier cable : 5 m
AC power cable for MT : 1.9 m



product_midasiao”>/LX Cable length X m(made to order)

Made-to-order cable with the length a customer requests.
*The length supported depends on the torque capacity. Please consult us for more details.
*Not applicable to CE marking



/GY Cable length Y m(made to order:worldwide type cable)

Made-to-order cable with the length a customer requests (for overseas specification)
*The length supported depends on the torque capacity. Please consult us for more details.
* Depending on the required power supply standard, it may not be possible to respond. Please consult us for more details.
*Not applicable to CE marking

Option (corresponding to each product)

MT-0100 series (calibrator for quick checking at site)

MT-0100 series

■ Calibration for detectors range: from 50 mN·m to 20 N·m
■ Calibration accuracy:
±0.5 %; detectors for 50 mN·m to200 mN·m
±0.4 %; detectors for 500 mN·m to 20 N·m
Calibration set to check the torque value at site.

MT-071 series (for current voltage measurement)

イラスト(外部電流電圧検出器)

■ For DC measurement:Used to set between a motor and a power supply device.
■ Voltage: 50 V
MT-0712: for 30A
MT-0713: for 50A
MT-0715: for 100A
MT-0717: for 200A
Made to order: for 2A/10 A

Brake Control Amplifier

Brake Control Amplifier

■ Required when large capacity type made-to-order detector is used.

■ TS-0875 (option) is required to attach to the TS-8700 when used with the TS-8700.







Sound Calibrator
Class1 SC-2500
Class2 SC-2120A

SC-2500A

SC-2120A

Lorem ipsum dolor sit amet, consectetur adipiscing elit. Ut elit tellus, luctus nec ullamcorper mattis, pulvinar dapibus leo.

SC-2500A

SC-2120

  • Conforms to IEC 60942:2017 Class 1, ANSI S1.40-2006 (R2011) Class 1, JIS C 1515:2020 class 1
  • Used for calibration of Class 1 and Class 2 Sound level meter
  • Since the SC-2500A uses the sound pressure feedback control method to control fluctuations in sound pressure caused by static pressure, it can generate a stable sound pressure even if the operating environment changes.
  • Cost-effective model.
  • Conforms to IEC 60942:2003 Class 2, JIS C 1515:2004 class 2
  • Dynamic speaker type
  • Simple type for quick operation check, cost-effective model

Specifications

Model nameSC-2500ASC-2120A
Applicable standardsJIS C 1515:2020 Class 1
IEC 60942:2017 Class 1
ANSI S1.40-2006 (R2011) Class 1
JIS C 1515:2004 Class 2
IEC 60942:2003 Class 2
MethodSpeakerSpeaker
Compatible products1/2-inch microphone : MI-1235/1271/1281*1/1433
1/4-inch microphone : MI-1531*2
High performance Sound Level Meter : LA-7200/7500/7700
Sound level meter : LA-1411/1441A/4441A
1/2-inch microphone : MI-1431/1432/1433
Sound pressure levelNominal sound pressure level : 114 dB
Deviation of sound pressure level:± 0.20 dB or less*3
Nominal sound pressure level : 94 dB
Deviation of sound pressure level:± 0.5 dB or less*3
Total distortion0.5 % or less*30.5 % or less
FrequencyNominal frequency :1000 Hz
Frequency deviation : ± 0.1 % or less*3
Nominal frequency :1000 Hz
Frequency deviation : ± 1 % or less*3
Operating environmentAir temperature : -10 to 50 °C (with no condensation)
Static pressure : 65 to 108 kPa
Relative humidity: 25 to 90 %
(Excluding a combination of air temperature and humidity that exceeds dew-point temperature of 39 °C or higher.)
Power requirementType AA battery (LR6 or HR6) × 29V flat battery (6F22 or 6LR61) × 1
Battery life10 hours or more continuous operation (when using LR6)20 hours or more continuous operation (when using 6F22)
Outer dimensions
(not including protruded section)
84 (W) × 53 (H) × 76 (D) mm52 (W) × 45 (H) × 130 (D) mm
WeightApprox. 220 g (including 2 battery cells)Approx. 300 g (not including battery cells)
AccessoryInstruction manual (J, E, C) × 1
Type AA battery (LR6) × 2
Protection cover for coupler × 1
Instruction manual × 1
9V flat battery (6F22) × 1

*1: This product is discontinued.

*2: SC-0313 adapter attached to MI-3140 1/4-inch preamplifier is required.

*3: The value under the standard environment (standard environmental condition:air temperature: 23 °C, static pressure: 101.325 kPa, relative humidity: 50 %)

Sound Level Meter
Class 1 LA-4441A
Class 2 LA-1411/1441A

ONO SOKKI’s sound level meters LA-1411/1441A (Class 2) and LA-4441A (Class 1) comply with IEC 61672-1:2013 and JIS C 1509-1:2017. These models can simultaneously measure seven sound parameters, including the equivalent continuous sound level, and display selected parameters without needing to adjust for sound fluctuation. Featuring an exclusive coaxial cable, the microphone can be used remotely from the main unit. With a curved body and intuitive menu, these meters offer enhanced usability. Additionally, the LA-1441A/4441A models can quickly transfer data to a PC via RS-232C or USB and can be remotely controlled from a PC.

LA-1411

LA-1441A

LA-4441A

●Sound level meter (Class 2) for product testing and measuring the sound level generated from machines etc.
●High-performance and cost-effective model

●Sound level meter (Class 2) for measuring the working environment and environmental noise
●Auto measurement function by timer and trigger.
●Level trend can be recorded at the interval from 1ms. (Lp memory function)
●Equipped with USB and RS-232C interfaces

●Sound level meter (Class 1) for sound analysis and product testing.
●Time weighting (10ms, Impulse) corresponding to the fast sound fluctuation.
●Level trend can be recorded at the interval from 1ms. (Lp memory function)
●Equipped with USB and RS-232C interfaces

Features

ONO SOKKI’s LA series sound level meters can simultaneously measure and selectively display seven sound parameters, including the equivalent continuous sound level (Leq). These parameters include time-weighted sound level (Lp), time-average sound level (Leq), sound exposure level (LE), maximum time-weighted sound level (Lmax), minimum time-weighted sound level (Lmin), peak sound level (Lpeak), and percentile sound pressure level (LN). The microphone can be detached from the main unit using exclusive coaxial cables, enabling distant measurements. By connecting to a Windows-based PC via RS-232C or USB, the LA series can easily and quickly transfer data to the PC and be remotely operated from the PC (excluding LA-1411).

System Configurations

Specifications

LA-1411LA-1441ALA-4441A
Applicable standard

IEC 61672-1 : 2013 Class 2

IEC 61672-1 : 2013 Class 1

JIS C 1509-1 : 2017 Class 2
JIS C1516 : 2020 Class 2

JIS C 1509-1 : 2017 Class 1
JIS C1516 : 2020 Class 1
Microphone

1/2-inch backelectret-type
condensor microphone MI-1433
Nominal sensitivity level:-29 dB

1/2-inch backelectret-type
condensor microphone MI-1235
Nominal sensitivity level:-29 dB

Preamplifier

MI-3111 Preamplifier for mocrophone

Linearity range

100 dB (Wide range), 80 dB (Normal range)

Measurable frequency range

10 Hz to 8 kHz(IEC, JIS)

10 Hz to 20 kHz(IEC, JIS)
Measurement level range

A : 26 to 135 dB(IEC, JIS)
C : 31 to 135 dB(IEC, JIS)
Z : 36 to 135 dB(IEC, JIS)

A : 27 to 135 dB(IEC, JIS)
C : 30 to 135 dB(IEC, JIS)
Z : 35 to 135 dB(IEC, JIS)
Frequency weighting

A,C,Z

Intrinsic noise

A : 20 dB or less
C : 25 dB or less
Z : 30 dB or less

A : 19 dB or less
C : 22 dB or less
Z : 27 dB or less

Level range

20 to 90 dB, 30 to 90 dB, 40 to 100 dB, 50 to 110 dB, 60 to 120 dB (Normal range),
70 to 130 dB, 40 to 120 dB (Wide range)

Time weighting

FAST, SLOW

FAST, SLOW, Impulse, 10 ms
Measurement itemsLp, Leq , LE, Lmax, Lmin, Lpeak, L(Lhigh, L5, L10, L50, L90, L95, Llow, Lave)
Level trendp, every kind of calculated value

Lp, every kind of calculated value
(Read out the displayed value as auto memory recall)

Sampling interval

31.25 μs (other than LN )
100 ms(LN)

20.83 μs (other than LN)
100 ms(LN)
Measurement timeManual, arbitrary setup (199 h 59 m 59 s max.)
Total measurement timeArbitrary setup (199 h 59 m 59 s max.)
Start modeManual onlyManual, timer (Hour,minute), trigger (can be started after a lapse of specified time [0 to 10 seconds, in increment of 1 minute] after trigger detection: trigger delay function)
Internal calibration signal (REFOUT)1 kHz sine wave (For upper limit level range : -6 dB(normal range), -16 dB(wide range))
Recommended sound calibratorSC-2500A,SC-2120ASC-2500A
DisplayLCD with LED backlight semitransparent (124 x 64-dot)
Measurement value display by numeric and bar indicators
List display and trend graph display for various kinds of calculated values
Displays of date, time, measurement time, and conditions of various kinds of instruments
Display update timeDisplay by numeric:1 s, bar indicator: 0.1 s, trend screen: 0.2 s
Manual memory functionTotal calculated values: 100 addresses
Auto memory functionLeq : 1000 addresses x 200 blocks
Total calculated values: 100 addresses x 200 blocks
Lp Record memory functionSound level with time weighting is stored at the specified interval. (1000 address × 200 blocks)
Storing intervals (1 ms, 2 ms, 5 ms and 10 ms)
Measurement condition memory functionCondition memories (9 kinds)
Resume functionSettings activated at power ON can be selected from follows; settings used at previous power OFF, factory setting, and any condition memory number which is set from menu.
Backup functionThe backup of data stored in clock and memory can be performed by built-in secondary power source.
• Time for full charged: approx. 24 hours
• Backup period: more than 3 months (when stored at temperature of 23 °C)
AC output *10.707 Vrms/F.S (normal range), 2.236 Vrms/F.S. (wide range), load resistance 10 kΩ or more (with upper-limitation value of bar indicator)

Frequency weighting can be selected: conjunction with selected frequency weighting or fixed to Z-weighting.

DC output *12.5 V/F.S. (with upper-limitation value of bar indicator)
Amount of voltage fluctuation per 10 dB: 0.25 V
Load resistance: 10 kΩ or more
External control inputOperation: toggle operation of start/place in pause

Specifications of hardware: negative pulse input
 (voltage level: Low:0.0 to 0.5 V, Hi:3.0 to 50 V)

Pulse width: 100 ms or more
Absolute maximum rated input voltage: 5 V

Comparator function

(Option: LA-0141) *2

Set comparison value : 40.0 to 130.0 dB(in increment of 0.1 dB)
Comparison item : Lmax or Lpeak
Delay time : 0 ms, 100 ms, 1 s, 5 s
HOLD time : 100 ms, 1 s, 5 s, manual
Output logic : negative or positive logic
Output format : open collector
(withstand voltage:+3 to +24 VDC, current:50 mA or less)
Timer functionBuilt-in (year/month/day/hour/minute)
RS-232C

Control of operation, data output, print out (to the DPU-414 printer)
Baud rate : 9,600/115,200 bps
USB

Control of main unit and data output,
USB 2.0 FULL SPEED (connecting virtual COM port)
Cable extension *3

(Between microphone and main unit)

305 m max.105 m max.
Printer function

Content:

Measurement value, measurement start/stop time,
measurement time interval, frequency weighting, time weighting
Mode:

Normal (alphanumeric) or screen image Applicable printer: DPU-414

Power requirementSize AA battery × 2 pcs.
(manganese (6R) or alkaline (LR6) or oxyride (ZR6)) or PB-7090 AC adapter (option))
Battery life (continuous using)Approx. 8 hours (LR6 alkaline battery in use / 23 °C/ backlight off / not RS-232C・USB in use)
Operating (storage) temperature range-10 to 50 °C (-20 to 60 °C)
Operating (storage) humidity range25 to 90 %RH (10 to 90 %RH) with no condensations
Outer dimensionsApprox. 78(W) × 263(H) × 47(D) mm
Weight
Approx. 360 g (including batteries)
Accessories

Windscreen×1 (φ 70 mm), carrying case×1, hand strap×1,
size AA battery × 2 pcs. instruction manual(CD), simple,operation guide

Option• LA-0141 Comparator output option
• SC-2500A Sound calibrator (Class1)
• SC-2120A Sound calibrator (Class2)
• AG-2010 Microphone extension cable (10 m)
• AG-2030 Microphone extension cable (30 m)
• AG-2050 Microphone extension cable with code reel (50 m)
• AG-2100A Microphone extension cable with code reel (100 m)
• PB-7090 AC adapter (120 to 240 VAC)
• AX-501 Signal input-output cable (2 m)
• AX-5022B RS-232C cable for PC (2 m)
*1 AC or DC output is selectable from menu of sound level meter.
*2 Comparator function (LA-0141, option) cannot be installed with the LA-1411.
*3 The cable length given here is the length when each of the exclusive cable sold by Ono Sokki is used. The cable length less than 30 m is applicable to CE marking.

Specifications

Accessories

Options

LA-0141 Comparator output function

OutlineThis optional function outputs the signal when value exceeds the setting value. Useful for the determination of sound level under measurement.
Specifications
Set comparison value40.0 to 130.0 dB(in increment of 0.1 dB)
Comparison itemLmax or Lpeak
Delay time0 ms, 100 ms, 1 s, 5 s
It can be used for the determination only when the measured value keeps exceeding against the setting value. Error-determination caused from single-shot sound can be avoided. When HOLD setting is manual, setting to delay conditions is automatically deactivated.
Hold time100 ms, 1 s, 5 s, manual
It is a time period to hold output signal even though measured value goes below the setting value. When the operating mode is manual, output signal is held until next measurement starts.
Output logicNegative or positive
Output formatOpen collector
(withstand voltage: +3 to +24 VDC, current: 50 mA or less)

Outline

The SC-2500A and SC-2120A are sound calibrators which are indispensable for sound measurement, conforming to JIS C1515:2004 ( and SC-2500A / IEC 60942:2020). The SC-2500A is Class 1 type sound calibrator with 1000 Hz and 114 dB output. It uses the sound pressure feedback control method to control fluctuations in sound pressure caused by static pressure to generate a stable sound pressure even if the operating environment changes. SC-2500A are recommended sound calibrator for LA-1411/1441A/4441A. The SC-2120A is Class 2 speaker type sound calibrator with 1 kHz and 94 dB output.

LA-0207A+LA-0208A All-weather windscreen

OutlineUsing the all-weather type windscreen reduces noise caused by the wind when performing sound level measurements outdoors, and prevents the microphone from being damaged by rain or snow. Screen diameter:Φ 200 mm
Mounting screw:1/4-20 UNS depth 6(screw for tripod attachment) * Applicable to JIS C 1509-1:2005 and IEC 61672-1:2002 when the LA-0207A and LA-0208A are attached to the sound level meter.
* Periodical exchange is necessary for the expendables (windscreen, waterproof mesh).
Illustration (AG-2000 series Microphone Extension cable)

AG-2000 series Microphone Extension cable

OutlineMicrophone can be used away from main unit of sound level meter by connecting exclusive coaxial extension cable. Using exclusive coaxial cable enables measurement of extension and moving the measurement place easier with small-type code reel.

Illustration (AG-2000 series Microphone Extension cable)

Others

・ MI-0301 Microphone holder is a standard accessory of each extension cable.
・ Conjunction cable (5 m) for connecting to main unit of sound level meter is attached to an extension cable with code reel.
・ Microphone can be used away from main unit of sound level meter by connecting several extension cables.

AG-2010 :10 m
AG-2030 :30 m
AG-2050 :50 m with code reel
AG-2100A :100 m with code reel

AX-501 Output cable

OutlineOutput cable for AC / DC signal output, comparator output, and external control signal input. It is used for the connection to FFT Analyzer, data recorder, PC, and sequencer etc.(2 m)

Illustration (AX-501 Output cable)

AX-5022B RS-232C cable

Outline

IF cable for connecting the LA-1441A/4441A and PC (RS-232C connector). (2m)

Illustration (AX-5022 RS-232C cable)

Tripod for sound level meter

Outline

Standard tripod for use with sound level meter.

(Airy L100, made by SLIK Corporation)

Photo (Tripod for sound level meter)

PB-7090 AC Adapter

Outline

Input voltage : 100 to 240 VAC
Output voltage : 5.9 VDC
Output connector : EIAJ RC-5320A Voltage category 2
Rated output current : 3.5 A
Total length: 3.5 m

* Please specify the input voltage of the adapter with your order; 120 to 240 VAC.

Photo (PB-7080 AC Adapter)

Microsoft ® and Windows ® are registered trademarks of Microsoft Corporation in the United States and other countries.
Other product names and model names are trademarks or registered trademarks of each individual company. The copyrights are reserved by each individual company.
Outer appearance and specifications are subject to change without prior notice.

Revised:9/11/2023

High precision Sound Level Meter
LA-7500

The LA-7000 series sound level meter features a large color LCD touch panel, significantly improving operation with its intuitive and easy-to-understand interface. This noise meter not only measures and computes noise levels but also allows for listening to the sound during measurement, facilitating the identification of sound sources and confirming recordings. With optional upgrades, it can evolve beyond a sound level meter to function as a sound analyzer, frequency analyzer, and sound recorder. The LA-7000 series enables efficient measurement work by combining noise measurement, sound recording, frequency analysis, and abnormal sound source detection in a single device. Furthermore, data saved with the LA-7000 series can be combined with various analysis software, enabling waveform analysis, sound quality evaluation, fluctuating sound analysis, and sound frequency simulation.

LA-7700

LA-7500

LA-7200

  • Class 1
  • Frequency range: 10 Hz to 20 kHz.
  • Measurement level range: 20 to 128 dB.
  • Self-noise level: Below 12 dB.
  • Class 1
  • Frequency range: 10 Hz to 20 kHz / 1 Hz to 20 kHz (with ultra-low frequency function).
  • Measurement level range: 24 to 138 dB.
  • Self-noise level: Below 16 dB.
  • Class 2.
  • Frequency range: 10 Hz to 8 kHz.
  • Measurement level range: 23 to 138 dB.
  • Self-noise level: Below 17 dB.

Features:

Ease of Handling:

  • 35% smaller than the previous model, making it easier to handle
  • Designed to prevent accidental drops


Intuitive Operation:

  • Clear overlay display and red warning for range overruns for easy understanding.
  • One-tap start for computation data and recording.
  • Ability to listen to the sound while measuring using the headphone.



User-Friendly Features:

  • Approximately 12 hours of operation with alkaline batteries, with USB power supply also available.
  • Easy switching of computation mode, range, and measurement time.
  • Basic screen return with the home key, and key lock with a long press.
  • Correction feature when using a windscreen.
  • Switchable display between Japanese and English.
  • Capability to capture and output images.
  • ON/OFF switching in conjunction with an external power source.

Standard Functions:

  • Modes: Offers SINGLE, DUAL, and QUAD modes for displaying computation values with different frequency and time weighting characteristics.
  • Listening Function: Enables measurement while listening, ideal for anechoic chamber measurements or remote monitoring.
  • 1/1 Real-Time Octave Analysis: Features RTA1/1 and Filter1/1 modes for detailed frequency analysis and focused listening in noisy environments.
  • Calibration History Feature: Facilitates easy management and verification of the noise meter’s performance.

Optional Features:

Option 1/3 Real-time Octave Analysis Function LA-0702

  • English: Enables detailed sound analysis and evaluation by dividing the octave band further. It’s possible to listen to sounds filtered through a 1/3 octave band filter. This is the most commonly used analysis function and filter for sound.

Option FFT Analysis Function LA-0703

  • English: FFT analysis allows checking the magnitude of sound for each frequency component. It supports automatic data saving and FFT analysis while recording. Improved resolution with 800 and 1600 lines.

Option Sound Recording Function LA-0704

  • English: Allows recording of audio data and playback on the sound level meter itself. Recorded files can be analyzed offline using O-Solution.

Option Offline Analysis Function LA-0704

  • English: Enables analysis of recorded sounds at a later time. Supports re-calculation and re-analysis (FFT, RTA, etc.) of Leq and other parameters.

Option Level Judgment Function LA-0705

  • English: Comes with an output cable and provides color-coded display when the set value is exceeded.

Option Level Simulator Function LA-0707

  • English: Allows listening to the sound after reducing the level of the problematic frequency band, and simulating the effect of the measures before implementation.

Option Sound Quality Evaluation Function LA-0708A

  • English: Effective for sound quality evaluation using loudness, sharpness, and Comfort Index, especially in cases where noise level assessments differ from human perception.

Option Ultra-Low Frequency Sound Measurement Function LA-0709

  • English: Capable of measuring ultra-low frequency sounds (1-20 Hz) that are inaudible to the human ear.



LA-7700 Class1LA-7500 Class1LA-7200 Class2
Applicable standardJIS C 1509-1: 2017 Class1
JIS C 1516   : 2020 Class1
JIS C 1509-1: 2017 Class2
JIS C 1516   : 2020 Class2
IEC 61672-1: 2013 Class 1IEC 61672-1: 2013 Class 2
ANSI S1.4-2014/Part1 Class1ANSI S1.4-2014/Part1 Class2
Measurement frequency range10 Hz to 20 kHz10 Hz to 20 kHz
1 Hz to 20 kHz*1
10 Hz to 8 kHz
Measurement level range (IEC, JIS)A: 20 to 128 dB
C: 28 to 128 dB
Z: 34 to 128 dB
A: 24 to 138 dB
C: 32 to 138 dB
Z: 38 to 138 dB
Z: 50 to 138 dB *1
G: 35 to 138 dB *1
or more*1
A: 23 to 138 dB
C: 30 to 138 dB
Z: 36 to 138 dB
Self-noise levelA: 12 dB or less
C: 20 dB or less
Z: 26 dB or less
A: 16 dB or less
C: 24 dB or less
Z: 30 dB or less
G: 27 dB or less*1
A: 17 dB or less
C: 24 dB or less
Z: 30 dB or less
MicrophoneMI-1281MI-1271MI-1471
Microphone preamplifierMI-3270
Linearity rangeWide range: 110 dB / Normal range: 80 dB
Level range10 to 120 dB (wide)/50 to 120 dB/40 to 110 dB/30 to 100 dB/20 to 90 dB/10 to 80 dB/0 to 70 dB20 to 130 dB (wide)/60 to 130 dB/50 to 120 dB/
40 to 110 dB/30 to 100 dB/20 to 90 dB/10 to 80 dB
Reference range50 to 120 dB
Time weighting e.g.: LAFF (fast), S (slow), I (impulse) and 10 msF (fast), S (slow), I (impulse), 10 ms and 10 s*1F (fast), S (slow), I (impulse) and 10 ms
Frequency weighting e.g.: LAFA, C and ZA, C, Z and G*1A, C and Z
Measurement itemsLp, Leq, LE, Lmax, Lmin Lpeak,
N (L5, L10, L50, L90, L95, Lhigh, Llow, Lave, and two more of any LN data)
Sampling interval15.6 µs (Lp, Leq, L E, Lmax, Lmin, Lpeak), 100 ms (LN)
Measurement timee.g.: If you want to measure a fixed 10-minute period every hour,
       and wish to measure this for 24 hours,
       M.T:10 minutes, P.T: 1 hour, and T.T: 24 hours
 Measurement time
(Meas.Time)
Manual (OFF), user-specified setup: 0.1 to 199 hour 59 min. 59.9 sec. resolution: 0.1 sec.
Period time
(Period Time)
1 min. to 24 hours / resolution: 1 min.
Total Time
(Total Time)
0.1 sec. to 999 hour 59 min. 59.9 sec. / resolution: 0.1 sec.
Start modeManual start, timer start, count down start, level start
Display device4.3-inch LCD with color backlight (touch panel type)
 Digital display4-digit/ resolution: 0.1 dB/ update cycle: 1 s
Bar indicatorWide range: 100 dB of display range/ Normal range: 70 dB of display range
Remaining battery level display4-step display
Operation mode(Online) mode
Standard: SLM-single, Dual, Quad, Filter 1/1, RTA1/1
Option: Filter 1/3 (LA-0702), RTA 1/3 (LA-0702), FFT (LA-0703), LSIM (LA-0707), SQE stationary sound (LA-0708A)
Standard: SLM-single, Dual, Quad, Filter 1/1, RTAl/1
Option: Filter 1/3 (LA-0702), RTA 1/3 (LA-0702), FFT (LA- 0703), LSIM (LA-0707)
*SQE stationary sound (LA-0708A) is not available.
Offline mode
(LA-0704 required)
Standard: SLM-single, Dual, Quad, Filter 1/1, RTA1/1
Option: Filter 1/3 (LA-0702), RTA 1/3 (LA-0702), FFT (LA-0703)
Overlay displayOverlay displayStandard: RTA 1/1
Option: RTA 1/3 (LA-0702)
Background noise correctionStandard: RTA 1/1
Option: RTA 1/3 (LA-0702)
Memory functionStored in an SD/SDHC card (SDHC card: up to 32 GB.)
 Memory mode
MANUAL (CSV file)………standard function
AUTO (instantaneous value, calculated value, CSV file)………standard function
LOGGING (instantaneous value, 10 ms or 100 ms, CSV file)………standard function
RECORD (WAVE file: 64 kHz sampling)………required for the LA-0704
Panel condition memoryInternal memory (internal condition : 5, EZ condition : 5, power off memory : 1),
SD or SDHC card memory (number : depends on the capacity)
Basic measurement mode5 modes (EZ1: LAeq+LCpeak, EZ2: Record, EZ3: Logging 100 ms, EZ4: NC, EZ5: Loudness)
Clock functionBuilt-in (year/ month/ day/ hour/ minute)
Continuous operation time : approx. 1 year (charging time: 24 hours from entire discharge state)
Calibration history functionBuilt-in memory (number of stored points: approx. 100 points),
Content (Calibration value, VR position for control, internal reference signal of
used sound calibrator, calibration date)
Resume functionStores measurement conditions into the built-in memory
CalibrationReference signal (when connecting external device)Electronic calibration by built-in transmitter (1 kHz sine wave)
Normal range: -6 dB of full-scale
Wide range: -16 dB of full-scale
Recommended calibratorSC-2500ASC-2500ASC-2500A, SC-2120A
Output/InputPhone output (headphone output)Actual sound or recorded sound (playback sound)
Selected 1 band of actual sound or recorded sound (playback sound) in 1/1 octave filter (standard function) or 1/3 octave filter mode (option: LA-0702)
When “UD” of level simulator (LSIM: LA – 0707) is selected, level editing sound. When “AP” is selected, the real sound.
Maximum output    : 0.03 mW (63 Ω: at 1kHz)
Connector              : stereo φ3.5
AC outputOutputs one of A, C, or Z interlocked with the main display
 AC output level
Output level: 0.707 Vrms ±5 (normal range), 2.236 Vrms ±5 (wide range) when range full-scale input,1MΩ loaded
Distortion rate (range full scale): 0.2 % or less
Load resistance: 10 kΩ or more
Offset voltage: ±30 mV or less
Output impedance: 50 Ω± 2%
AC/DC outputSelectable form DC, AC-Z or Through
 DC output level2.5 V ±20 mV (normal range, wide range) when range full-scale input,1MΩ loaded
Scale factor: 0.25 V±10 mV/10 dB
Load resistance: 10 kΩ or more
Output impedance: 50 Ω ± 2%
AC-Z output level
Output level: 0.707 Vrms ±5 (normal range), 2.236 Vrms ±5 (wide range) when range full-scale input,1MΩ loaded
Distortion rate (range full scale): 0.2 % or less
Load resistance: 10 kΩ or more
Offset voltage: ±30 mV or less
Output impedance: 50 Ω± 2%
Through output level0.707 Vrms ±5 % (normal range/ wide range) when full-scale input, 1MΩ loaded
Distortion rate (range full scale): 0.2% or less
External control input
Operation: Reset and start
Control voltage: non-voltage contact input
Input pulse width: 200 ms or more
Absolute max. input voltage: 24.0 V
Level judgment output(*LA-0705)Open collector (output withstand voltage : DC+24V or less, sink current : 20mA or less)
*Output cable (Multi I/O -BNC connector 2 m) : provided as standard
 Level judgment comparison itemSLM mode (Main : Lp), Filter 1/1,1/3 (Main (BP) : Lp), RTA1/1,1/3 (AP1 : Lp), FFT (OVERALL : Instant)
InterfaceRS-232CBaud rate: 9600, 115200 bps, multi I/O cable (sold separately)
USB



Compliant with USB high speed storage class specification ver. 2.0,
USB connection calbe: USB (A) male-USB (mini) male (sold separately)
Function: Command control or mass storage*2
External memorySD/SDHC memory card (SDHC : up to 32 GB)*3
Applicable extension cable
(for microphone extension) *4
103 m (CE conforming cable: up to 30 m)…AG-3400 series
*Cable extension exceeding 5m : with correction function.
Power supply· Size AA battery (alkaline battery cell or Ni-MH secondary vattery) x 4 pieces
· USB bus power (operating input voltage range: 4.75 to 5.25 VDC)
· AC adapter (PB-7090, power consumption: approx. 7 VA when using 100 VAC)
External power operation functionThe main unit is activated automatically when the power is supplied from an AC adapter.
(This function is not available by battery cells.)
Switch on/off can be done with the switch in the battery box (standard function)
Windscreen correction functionFunction to correct the influence of windscreen (φ70)/
All-weather type windscreen (LA-0207A)
LA-7700 : all-weather type windscreen cannot be used with
Battery life (continuous use) *5Alkaline battery cell LR6   : approx. 12 hours
Ni-MH secondary battery: approx. 12 hours
Operating (storage) temperature range-10 to 50 °C (-20 to 60 °C)
Operating (storage) humidity range20 % to 90 %RH (10 % to 90 %RH ) with no condensation
Outer dimensionsApprox. 90(W)×279(H)×42(D)
WeightApprox. 540 g (including batteries)
Accessories·AC adapter (PB-7090)*6
·Hand strap
·SDHC memory card (4G)
·Signal cable (AX-501)
·Size AA battery cell x 4 pieces
·Iinstruction manual (CD)
·Windscreen (φ70 mm)
·Carrying case (including shoulder belt)
·Setup guide

*1: Available with the LA-0709 Ultra low frequency sound measurement function
*2: Supported ver.2.0 or higher version of firmware
*3: Please use a recommended SD card when you use the SD memory function.
*4: The described value is extendable length when the exclusive cable is used.
*5: It depends on the using status such as operation mode, memory mode, and backllight.
*6: Please contact your nearest distributor or Ono Sokki sales office nearby for the outlet cable used for overseas.

Option

ModelName
LA-07021/3 Octave Analysis function (RTA mode/Filter mode)
LA-0703FFT Analysis function (Narrow band frequency analysis)
LA-0704Sound recording function / Offline analysis function
LA-0705Level judgment function
LA-0707Level simulator function
LA-0708ASound quality evaluation function
LA-0709Ultra low frequency sound measurement function



Measurement Microphone MI series

A variety of lineup for the acoustic measurement

The MI series are back electrets and sound field type measurement microphones.

The lineup is as follows:

– Measurement Microphone;
– Microphone Preamplifier; and
– TEDS Microphone

MI-1271/MI-3170 Microphone/ Preamplifier

MI-1271/MI-3170
Microphone/ Preamplifier

New Website coming soon

New Website coming soon

Torque Station Pro TS-8700

Previous slide
Next slide

TS-8700 Torque Station Pro is torque measurement system for motor basic property with high precision and high response.
In combination with the motor torque detector MT series with the TH series torque detector, it is possible to perform high-precision, high-response motor torque measurement with up to 5.12 kHz sampling and ± 0.1 % of accuracy.
In addition, the high rigidity compact torque detector RH series (10 N・m/ 20 N・m) can be mounted on the MT series. It has achieved more highly accurate measurement with ±0.05 %/F.S.
This system is ideal for measuring torque fluctuations of motors on-board such as EPS motors.

  • Switching function of motor torque detector is built-in.
  • 2 channels as standard, up to 4 channels as options
  • Link function with OC-1300 series, OS-2000 series to help effective data processing from measurement to data organization
  • Various types of detectors (MT series) for the TS-8700 are available to support various motor characteristic measurement
  • Selectable from three series according to the purpose; for high speed rotation motor, large capacity motor, and torque ripple/cogging torque. There are three types including general, high performance and high precision, and 58 models in total.

Feature

High precision/ high response

When combined with the MT detector with the TH type torque detector, the torque measurement accuracy is ± 0.1% and the maximum sampling frequency is 5.12 kHz.
In addition, a new compact high-rigidity torque detector RH type can be mounted. The RH type torque detector (10 Nm / 20 Nm) is a torque detector that achieves high accuracy (± 0.05% F.S.) and high rigidity (4.5 times that of our existing models). It enables to measure torque fluctuations of motors in a higher frequency range with higher accuracy.



Temperature measurement*, temperature trigger measurement*

8ch temperature measurement with a T-type thermocouple, and temperature trigger function are optionally supported. They allow starting measurement automatically after warm-up operation.



Rotation angle measurement*, rotation angle sampling*

>Rotation angle and angle sampling are measured by using the pulses from encoder built-in a target motor. When an encoder is optionally added to the MT-82 T/M (except certain models) detector for cogging torque/torque ripple measurement, rotation angle and angle sampling can be measured in units of 0.1°.

Link function to OC-1300 series Graph creation software, and OS-2000 series Time series data analysis software

Data of measurement result can be transferred to OC-1300 series and OS-2000 series immediately by link function. You can transfer data of measurement results by the link button.
•Efficient and speedy report creation by using a template of OC-1300 series, such as a calibration certificate or others.
•Data evaluation in same time axis by OS-2000 series
The torque data measured by TS-8700 and the sound/vibration data recorded by DS-3000 can be evaluated in the same time axis on the OS-2000 series with this link function.
•Further analysis including FFT analysis can be performed as a secondary processing with the OS-2000 series.

Link function to DS-3000 series

Using this function, you can make measurement start/stop the DS-3000 synchronizing with those timing of TS-8700.
(Using EXT SEQUENCE2 as a DS synchronization signal can reduce the influence of the delay in recording start due to communication, compared to Link measurement on a LAN connection.)

Data communication with a power meter made by other company*

The measurement data of the following four specified power meters made by other companies can be saved digitally via LAN connection.

  • WT1800E, WT300E (WTViewerEfree*1Ver1.42 or later used) : made by YOKOGAWA ELECTRIC
  • PW3390, PW3337 (PW Communicator*2Ver1.7.0 or later used) :Made by HIOKI E.E. CORPORATION

*:Optionally available
*1:WTViewerEfree is registered trademark of YOKOGAWA ELECTRIC.
*2:PW Communicator is a registered trademark of HIOKI.E.E CORPORATION



















Freely selectable system component

You can select devices according to the torque capacity to be tested or setting place. (Desktop type, Floor type stand with caster, XYZ stage, slide base, V block, L bracket etc.)
*Device to be selected may be limited depending on models or torque capacity. Please consult your nearest distributor or Ono Sokki sales office.

System of Link function to DS series (Data Station) •OS-2000 series (Time-series data analysis) •OC-1300 (Graph creation)

Data example

Can be used in a software for word processing or spreadsheet

Calculation display of efficiency
(Required current voltage detector separately)

Measurement data of Revolution-Torque characteristics

Measurement data of torque rippl

Application example

Measuring torque characteristic of DC motor

· The above example shows how to measure and display as graphs the characteristics of DC motor of torque, rotational speed, current, voltage. The efficiency performed by internal calculation also can be displayed.

· The MT-0710 series voltage/current detector (sold separately) is required.

System configuration





Measurement prodedure(Movie)







Measurement procedure of MT-8000 series/TS-8700

Overview specification

Measurement targetDC motor, AC motor (excluding stepping motor)
Measurement parameterTorque, rotation, voltage signal input data, temperature*,rotation angle*,power meter digital input*
Torque inputUse signals form Ono Sokki’s exclusive detector (MD/SS,TH/RH/TQ*) , external torque analog input*
Revolution inputUse signals form Ono Sokki’s MP-981 or RP series detectors
Analog input0 to ±10 V DC, 16 channels, 16 bit A/D   Connection cable: customer prepared
Temperature inputType T thermocouple*    T-type thermocouple: customer prepared
Measurement accuracyTorque**±0.05 %/F.S.(RH *,TQ *)
±0.1 %/F.S.(TH-1000/2000 *)
±0.2 %/F.S.(MD/SS、TH-3000/H)
Revolution speed**MT-84M/T/R series, MT-85M/T/R series ±0.02 %/F.S. ±1 count
MT-82T (excluding MT-82T15, MT-82T25 ±0.06 r/min
MT-82M, MT-82T15, MT-82T25,MT-82R15,MT-82R25 ±0.02 r/min
AnalogLinearity : ±0.1 %/F.S. Or less(1 second average), temperature drift:±0.01 %/F.S./°C
TemperatureConversion accuracy : within ±[0.5 % of span + 0.5 °C {thermosensitive element accuracy}]
Temperature drift : ±0.2 % or less of span to the change of 10 °C

*: Option
**: After N-0 compensation. 1-second averaged value
•Excluding the influence of fluctuation component comes from equipment component and resonance component including the measurement data-target



Computing equationFour arithmetic expression (The operation items can be defined by input signals and existing calculatd data.)
Measurement condition setting

Setting of torque detector, revolution detector

Control methodRevolution/torque
Measurement mode: Automatic/manual
Can be saved with a file name.
Measurement function◎Fixed value
measurement:
measurement time2 to 28,800 seconds
Number of data• SS/MD:512/1024/2048/4096/8192/angle Sample
• TH :2048/4096/8192/16384/32768/Sample
• TH high response (available when TS-0871 option installed)
   :10240/20480/40960/81920/163840/Sample
• RH/TQ (available when TS-0882 option installed)
   :10240/20480/40960/81920/163840/Sample
• EXT TRQ IN (available when TS-0873 option installed)
   :512/1024/2048/4096/8192/Sample
(Angle Sample: available only when manual operation (N) ,
and the measurement time is limited to 60 seconds or 120 seconds.)
◎Sweep measurementmeasurement timeDepending on the number of data.
512 : 2 to 1000 seconds
1024 : 4 to 1000 seconds
Number of data• SS/MD : 512 / 1024
• TH : 2048 / 4096
• TH high response (available when TS-0871 option installed) : 10240 / 20480
• RH/TQ (available when TS-0882 option installed) : 10240 / 20480
• EXT TRQ IN (available when TS-0873 option installed) : 512 / 1024
◎Step measurementNumber of steps2 to 128
Calculated automatically from the upper/lower limit torque or upper/ lower limit rotation speed and step width.
Step time5 to 100 seconds
◎Pattern measurementNumber of patterns1 to 128
Number of repeat times1 to 10
Shift time1 to 100 seconds
Monitor displayNumeric value display : Max. 100 items can be displayed simultaneously
Trend display:Time axis display
Graph display

Display by specifying X-axis, Y-axis from the measured data

Graph enlargement/reduction, specifying line color/line width, comment input, text display and text saving on the graph, cursor/peak search function, overlay display function, max. 16 files

Table displayList display of measured value, data edition function
ComparatorUpper/lower limit of selected items can be specified, max. 4 points to max. 6 items, display and output of judgment result
I/F for MT series detector2 channels, (4 channels as an option)
Saving measurement resultsData saved in an exclusive format or text format
Operating environment of a PC

PC specification that TS-8700 software can be operated on
•CPU Intel®™ Core®i5 or higher (recommended)
•4 GB or more of free memory (recommended)
•HDD/SSD 256 GB or more (recommended)
•Optical drive: Optical drive that can read CD-R for installation or update
•OS:Microsoft®Windows®10 Pro (64-bit) •English or Japanese version • Version 1803 or later

•Display: 1366 x 768 (full wide XGA) or more
•LAN port: Ethernet 100BASE-TX
* Not all the PC satisfying the above specifications are guaranteed to operate. Please supply a PC to check the operation.

Power requirementAC100 to 240 V± 10 %, 50/60 Hz
Power consumptionApprox.200 VA (AC100 V) or less
Isolation resistance10 MΩ or more (rated voltage DC 500 V)
Withstand voltageAC 1500 V for 1 minutes
Temperature/humidityOperating temperature range: + 5 to + 35 °C
Operating humidity range: + 30 to + 80 % RH (with no condensation)
Storage temperature range: − 10 to + 55 °C
Storage humidity range: + 30 to + 80 % RH (with no condensation)
Altitude condition etc.

Pollution degree: 2

Installation category: Category 2, indoor use
Max. altitude: 2000 m
With no condensation
Without no corrosive gas

Outer dimensions420 (W) x 149 (H) x 450 (D) mm or less
WeightApprox. 15 kg
Conforming standard
CE markingLow voltage Directive:2014/35/EU EN61010-1
EMC Directive:2014/30/EU EN61326-1 class 1 Industrial environment
RoHS Directive:2011/65/EU EN IEC 63000
FCCCRF47 Part15 Subpart B class A

MT8M: CE not supported
MT-0100 series, MT-071 series: RoHS not supported

AccessoryAC power cord, application CD-ROM, LAN cable (2m)
Others

*MT series detector and detection stand for motor etc are required separately.

* Adjustment fee is separately required for matching to the MT series detector.

Option

TS-0871
TH highly responsive samplingAdds the highly responsive sampling function of the TH detector (supports 5120 Hz)
TS-0872
Analog/pulse outputAdds torque/rotation speed analog output, and rotation speed pulse output function.
TS-0873
External torque/analog inputRequired when the torque control is used in the analog output of the torque detector.
TS-0874
Additional detector interfaceConnects four or more MT series torque detectors
TS-0875
Interface for BA-910ARequired when the BA-910 type power amplifier is used.
TS-0876
Temperature measurement/temperature trigger

Required for temperature measurement.

• Eight connectors (male) for sensor side are provided as standard.
TS-0877
Angle measurement/angle samplingAdds the angle sampling function of external encoders
•Cable side connector (R03-PB8M) is provided as standard.
TS-0878
Link to DS-3000Links to DS-3000 series made by Ono Sokki
TS-0881
Power meter digital communicationConnects to power meter made by other company via LAN, and loads the measurement values digitally.
TS-0882
Additional TQ/RH detectorIt can connect the TQ/RH series torque detectors.

Portable 2 channel/4 channel

FFT Analyzer CF-9200A/9400A

The CF-9200A and CF-9400A are an all-in-one portable FFT analyzers. All FFT analysis operations can be performed with the integrated hard keys and capacitance type touch panel without requiring an external PC for analysis. The new, exclusively developed 100kHz high-performance analysis front-end system incorporating a 24-bit A/D converter enables easier and more reliable analysis of noise and vibration generated by plant lines, pumps, motors, automobiles, railway vehicles, home electrical appliances and devices, and electrical and electronic parts than previous models. The CF-9200A and CF-9400A also offer solutions for field workers in their FFT analysis, including the resonance and frequency characteristics of mechanical structures in a vibrating environment with electromagnetic vibrators and impulse hammers.

Features

Speedy

     Keys and a touch panel for quick, light and intuitive operation

With the CF-9000A series, basic FFT analysis operations such as display, measurement, stopping, recording and readout can be made positively and quickly through the large hard keys. The touch panel provides an intuitive interface, allowing the operator to easily perform a range of operations with a swipe or tap, such as selecting the number of waveforms displayed and extending or shortening the X and Y axes to the desired scale.

Flexible

     Hot-swap & cordless 5 hours operation

With the CF-9000A series, basic FFT analysis operations such as display, measurement, stopping, recording and readout can be made positively and quickly through the large hard keys. The touch panel provides an intuitive interface, allowing the operator to easily perform a range of operations with a swipe or tap, such as selecting the number of waveforms displayed and extending or shortening the X and Y axes to the desired scale.



*1 When CF-9400A 4ch CCLD ON.
*2 Full recharge takes 7 or 8 hours depending on operating conditions.

Versatile

     Recording & performing analysis (FFT or RTA) simultaneously

The unit is compact but versatile, capable of carrying out a range of operations from FFT analysis, real-time octave analysis (RTA) *1 and rotation tracking analysis*2, to linear/log sweep analysis using signal output and electromagnetic vibrator control*3. The unit can also perform simultaneous analysis and recording operations, allowing offline analysis back in the office using the CF-9000A main unit and software applications.

*1 Octave analysis software (CF-0923) is required.
*2 Tracking analysis software (CF-0922) is required.
*3 Log sweep/excitation control software (CF-0942) is required.

Quiet

     Noise or vibration-free operation in a fan-less, spindle-les design

The unit is compact but versatile, capable of carrying out a range of operations from FFT analysis, real-time octave analysis (RTA) *1 and rotation tracking analysis*2, to linear/log sweep analysis using signal output and electromagnetic vibrator control*3. The unit can also perform simultaneous analysis and recording operations, allowing offline analysis back in the office using the CF-9000A main unit and software applications.

*1 Octave analysis software (CF-0923) is required.
*2 Tracking analysis software (CF-0922) is required.
*3 Log sweep/excitation control software (CF-0942) is required.

Standard functions

Real-time tripartite graph/VC Curves* (Vibration Criterion Curves) display function

The CF-9200A/9400A comes with a new real-time tripartite graph*1 display function.
During FFT analysis, three amplitude values (acceleration (m/s2) /velocity (m/s) /displacement (m) ) for an arbitrary frequency can be read out in real time. This function will eliminate the need to convert the amplitude by carrying out differentiation and integration individually by the frequency analysis function as with the previous models, thus enabling data at that amplitude to be read speedily. Displaying VC curves*2 after 1/3 octave processing helps to judge the allowable vibration reference or setting environment evaluation of precision instrument which is sensitive for vibration such as AFM, electronic microscope and laser interferometer.

*1 Amplitude of acceleration (m/s2) and displacement (m) based on the velocity (m/s) on the frequency axis (Hz) can be read by Tripatite graph (image).

*2 VC Curves are proposed as the allowable minute vibration reference of when precision instrument is set. The evaluation by 1/3 octave band width is used in VC Curves. The standard is divided into five stages in increments of 6dB (VC-A, VC-B, VC-C, VC-D, and VC-E) depending on the purpose of use such as optical microscope and laser instrument with long optical path.

Generic Vibration Criteria for Vibration-Sensitive Equipment, Colin G.Gordon, SPIE99Evolving criteria for research facilities: I-Vibration

Wide & dynamic range

The CF-9000A series features a new 24-bit A/D front-end system, offering 120dB wide dynamic range. This eliminates the need for voltage range change in A/D oversampling, which otherwise needs to be frequently performed in acoustic or vibration measurement.

Measuring and data recording do not need to be repeated, making calculation and analysis much more efficient and the FFT analyzer easier to operate even for novices.

Isolated all inputs

With the CF-9000A series, all signal input channels are isolated (insulated). Highly resistant to ground loops and noise, the unit offers highly reliable measuring performance in locations prone to potential difference.

The isolation scheme also protects the crucial areas of the FFT system from sensors or signals that can be exposed to harmful transient voltages.

CCLD*equipped, TEDS*available

By each input channel with CCLD, an accelerometer with built-in preamplifier, charge convertor for charge output type accelerometer or a microphone can be connected directly to the CF-9200A/9400A. And using TEDS sensor enables power supply and unit calibration to sensor automatically.

*CCLD (Constant Current Line Drive) means the sensor interface using Constant Current Supply. CCLD from an accelerometer with built-in preamplifier or a microphone preamplifier enables direct connection to an FFT Analyzer without using external amplifier. 2 to 4 mA of CCLD is commonly used.

*TEDS (Transducer Electronic Data Sheet) is a general term for the method which contains information relevant to the sensor. It is defined in the IEEE 1451 series. As information of the sensor is automatically read to the TEDS available measurement devices or amplifiers, the user is ready to take measurements. It can avoid setting error and also saves you time and effort of troubling calibration and measurement preparation.

Easy operation through a touch panel interface

The CF-9000A series employs a 10.4 LCD capacitance type touch panel, allowing the operator to pinch and swipe FFT graphs. The band or gain of your choice can be widened or narrowed with a simple and intuitive action.

Reliable inputs with the new hard keys

With the CF-9000A series, operations such as turning the power on and off, changing data types and saving data are carried out using the new large hard keys. The positive feel of these keys assists fast and correct input even in unstable or dark sites, helping to prevent failures to save data and malfunctions caused by inadvertent inputs. Lock function (HOLD) for hard keys and touch panel are also effective.

Highly visible LED indicators

The status of major FFT operations are shown by LED indicators. The hard keys for major functions also have LED indicators. This enables the operator to monitor FFT operations even from a distance, such as the power-up process, the charge status of the secondary batteries and A/D oversampling.


Cable disconnection detecting function

Automatically detects cable disconnection or connector trouble of an accelerometer and a microphone*, preventing trouble before measurement. With the CF-9000A series, this function can be made disable.

*Built-in preamplifier CCLD type



FFT Basic analysis functions

Time-axis waveform

Performs A/D conversion of the raw waveform of an electrical signal of vibration, noise, pressure, strain, etc. coming from a sensor and then displays the result as time-domain data.
The X and Y-axis values at any point can directly be read using the search cursor. The delta cursor function makes it easier to read the time difference and level difference.
The time-axis data analysis function enables quantitative time-axis waveform analysis and diagnosis of such items as mean value (MEAN), root mean squared value (RMS) and crest factor (Crest Factor).


Torque Meter TQ-5300

TQ-5300 Torque meter, used with the TQ-2000 series High-stiffness torque detector, can convert the pulse output of the detector to digital torque value and analog voltage output.

Four kinds of digital interface (newly added EtherCAT, CAN, and existing RS-232C) are provided as options as digital output, which allow digital communication at higher speed. These digital interfaces can output torque measurement value without decreasing accuracy that the torque detector originally has.
High speed response analog output is enabled by adopting periodical calculation method to convert it for every one cycle of the pulse.

Remote I/O function, communication function, and interlock function are provided as standard, which are very useful for assembled system.

Optional multi-range function (TQ-0536) covers settings for multiple torque capacities in one torque detector.

Features



Four kinds of digital output

· High accuracy output of torque measurement value

These digital interfaces allow output of torque measurement value without decreasing accuracy that the torque detector originally has.

· Digital interface (option)

■ EtherCAT (TQ-0535)
■ CAN (TQ-0533)
■ RS-232C (TQ-0532)

Multi-range measurement function



Optional multi-range function (TQ-0536) covers settings for multiple torque capacities in one torque detector. No need to replace a torque detector for measurement of different torque capacities. You can easily switch measurement range by saving information of the torque detector including factor, capacity, etc. in advance



● Up to 3 of range settings for different torque capacity
● Range switching by menu mode or external mode.
● Measurement error is prevented by checking current range setting with range output when switching ranges in external mode.

*Please consult before the order when you use the multi-range function. Setting conditions should be decided according to the torque range used.

Analog output at high speed response

Signal output frequency detected by the TQ-2000 detector fluctuates according to the amount of torque detected. The TQ-5300 torque meter calculates for every one cycle the frequency which corresponds to the detected torque amount, and outputs them as analog signal at high response. It enables optimum control by following up the transient torque having wide fluctuation.



Used with TQ-3507 High Stiffness Torque Detector

TQ-3507 high stiffness torque detector is optimum for the motor torque test which requires high speed rotation such as a motor for driving EV/HEV.



Analog output of rotation speed

Simultaneous analog output of torque·rotation speed value.
Using TQ-0531 (option) enables 2-ch output of torque signal.
This function is helpful when you use outputs in different purpose. For example, you can output data for controlling and recording with a single torque meter.

Example of display screen

Measurement:

Display type is selectable from single-stage display (torque value) or two-stage display (torque and rotation speed)

●Main display

●Two-stage display(torque, rotation speed)

Comparator output:

When the torque value exceeds the torque value specified in advance, it is considered to be abnormal and contact output is executed.
As for comparator output, it has three channels to be set. Two channels are able to be set the value freely, and comparator output is automatically performed from one channel when torque value exceeds the 110% of the maximum. Two channels which can be freely specified are able to be set to rotation output.

●Comparator ON(single-stage)

●Comparator ON(Two-stage)



Setting

●Condition setting

●Communication interface selected(option)

Application

Engine test bench

It provides data to reproduce virtual load faithfully in an engine bench.
High accurate and high response torque data is able to be obtained by theTQ-5300 in which digital interface is equipped.

Transmission test equipment

One torque detector supports various tests including engine endurance test, efficiency test by using multi-range function.
Stable measurement is possible because there is no need for replacing torque detector according to the torque value of the test.

Specification

Input section
Torque

Input format

Line driver input

Input frequency range

1 kHz to 25 kHz
Applicable detectorTQ-2000 series
ConnectorD-sub 15 PIN(female)
Rotation speedApplicable detectorMP-981、MP-9820

Input frequency range

1 Hz to 100 kHz

Signal amplitude range

High level +5 V ± 0.5 V
Low level 0.5 V or less

Connector

R03-R6F(TAJIMI Electronics Co., Ltd.)
Display
Torque

Number of display digit

Polarity + 5 digit (excluding decimal point)

Unit

N·m、kN·m

Accuracy

± 0.008 %/F.S. ± 1 count
Rotation speed

Number of display digit

Polarity + 5 digit

Unit

r/min

Accuracy

Display value × (±0.01 %) ± 1 count
Output section (Analog output)
TorqueOutput formatVoltage output 0 to ±10 V/F.S

Analog conversion method

Periodic calculation method

(Calculates for every one cycle to frequency, and converts to analog output)

2 CH switching(option)

2 CH of output item selectable from torque or rotation speed

Analog conversion time

1 period +5 µs or less

Minimum acceptable load

100 kΩ
Accuracy± 0.05 %/F.S.
ConnectorD-sub 9PIN(male)
Rotation speedOutput formatVoltage output 0 to ±10 V/F.S

Analog conversion time

1 ms or less

Minimum acceptable load

100 kΩ
Accuracy± 0.3 %/F.S.
ConnectorD-sub 9PIN(male)
Output section (Pulse output)
TorqueOutput itemPulse output from torque detector after waveform shaping.
Output formatOutputs after pulling up the open collector output to +5V with resistance 330Ω)

Pulse width

Depending on the output width of sensor

Minimum acceptable load

10 kΩ
ConnectorD-sub 9PIN(male)
Rotation speedOutput itemOutput from rotation speed detector after waveform shaping
Output formatOutputs after pulling up the open collector output to +5V with resistance 330Ω)

Pulse width

Depending on the output width of sensor

Minimum acceptable load

10 kΩ
ConnectorD-sub 9PIN(male)
Interface section
REMOTE

External input item

Selection of rotation direction:contact input
Torque zero-correction value

Contact close at CCW

Torque zero correction value acquisition start:Contact input
*Displays the torque value to be zero under no load condition automatically by external contact point

This function automatically displays the torque value zero when no load condition by external contact point.
Selectable among 3conditions by switching external input signal (option).
External output item

READY:contact output

Contact point is closed when torque measurement condition.

Comparator:contact output
3 ch(optionally setting alarm: 2 ch, fixted internal channel: 1 ch)

Confirmation of setting condition

Open collector output 2 ch(Outputs available conditions by 2-bit.)

Communication interface
RS-232C (option)

Standard

Conforms to RS-232C

Baud rate9600/38400 bps
Communication methodAsynchronous full-duplex mode
ConnectorHR12-10R-8SD(HIROSE ELECTRIC CO., LTD.)

Communication interface

CAN output
(option)



ProtocolConforms to CAN Ver2.0B
Baud rate

125 /250 /500 kbps

1 Mbps

Output update cycleOFF/1/2/5/10/20/100 Hz 1 kHz
Output itemTorque value / rotation speed value
ConnectorD-sub 9 PIN(male)
Baud rate9.6/19.2/93.75/187.5/500 kbps
1.5/12 Mbps
Output itemTorque value, rotation speed value, setup item (CAPACITY,FACTOR)
ConnectorD-sub 9PIN(female)

Communication interface

EtherCAT
(option)



ProtocolConforms to IEC61508
Baud rate10/100 Mbps
Output itemTorque value, rotation speed value, setup item (CAPACITY,FACTOR)
ConnectorRJ45 Ethernet Connector Channel0, Channel1
Communication interface mounting methodSimultaneous installation of communication options is not available excluding the combination of RS-232C and CAN.
General specification

Power voltage

DC 24V (18 to 30 V )

Power consumption

20 VA or less (when connected sensor, excluding option)

Operating temperature range

0 to 50 ℃
Operating humidity range20 VA or less (when connected sensor, excluding option)

Storage temperature range

0 to 60 ℃
Storage humidity range20 to 85 %(with no condensation)

Outer dimensions

170 (W) × 49 (H) × 150 (D)mm(excluding protruded section)

Weight

Approx. 700 g
CE markingLVD Directive:2014/35/EUEN61010-1 class1
EMC Directive:2014/30/EUEN61326-1 class1 Industrial setting
RoHS Directive:2011/65/EUEN50591
FCCCFR47 Part15 SubpartB class A

Accessory

DC power input connector × 1, Connector for REMOTE × 1, analog·pulse output connector × 1, rubber foot x 4, instruction manual × 1
Note
The TQ-5200 Torque Convertor is used with as display unit.
Linearity includes hysteresis.

Option

Model nameProduct name
TQ-0531Analog output switching function
TQ-0532RS-232C communication function
TQ-0533CAN output function
TQ-0535EtherCAT communication function
TQ-0536Multi-range function
TQ-0811Remote cable 2 m
TQ-0821Analog·pulse output cable 2 m
CT-0673Panel mounting fixture

Rear panel(with options)

●With EtherCAT

●With CAN, RS-232C

* Simultaneous installation of CAN and RS-232C is available.

Digital Torque Meter
TS-2800

The TS-2800 is a torque meter for phase difference type torque detectors. Can be used with our long-selling torque detectors SS/DD series and high accuracy, high response type TH series. Since all signals are digitally processed, torque measurement can be performed with great stability, reproducibility and linearity.



The TS-2800 can output analog voltage, rotation pulse*, BCD*, and RS-232C as well as displaying measurement values digitally. Compact and space-saving design is enough to fit your measurement system yet the installation space are limited.

*: option

Features

  • • Can be connected all of phase difference type torque detectors by Ono Sokki.
  • • Analog output response (time constant) can be selected depending on your application.
  • • 4th order butterworth low-pass filter can be selected for analyzing frequency of torque ripple. (TH mode, option)
  • • F.S. voltage of torque output can be selected according to the input range of a recorder or other devices to be connected.
  • • Output of rotation pulse signal required for rotation tracking analysis of torque ripple
  • • Easy to read, easy to operate with LCD.

System Configuration

Application

Measuring torque ripple for each rotation speed of a small motor. (Tracking analysis of rotation speed)

Motor torque varies repeatedly with constant period and constant width due to interlinkage magnetic flux. The difference between the maximum and the minimum torque compared to the average torque is defined torque ripple. Measuring torque ripple arrives at solution for sound and vibration problems, and less ability to control caused by electromotive force.

Checking hinge torque characteristics of OA equipment, cell phones etc.



This example shows how to measure the torque characteristics of hinges used in various products such as electric home appliance (rice cooker or microwave), OA equipment (fax or copy machine) and PCs or cell phones. Measuring torque characteristics is used to control product quality. For example, it is effective in checking whether hinges meet specific requirements and characteristics or not.



• Checking the force required to open and close

• Checking the changes of hinge characteristics after tens of thousands of opening and closing tests

 Overview specification

Applicable detectorTorque detectorPhase difference type torque detector (TH,MD,SS, DD, EZ, DSTP, DP)
Rotation detectorMagneto-electric rotation detector (MP-981/9820), optical rotation detector (MD-0100series), SIG2 output signal of torque detector (excluding TH type)
DisplayDisplay contentsMeasurement value: torque, rotation speed
Condition display: sensor mode, measurement ready, torque signal input, rotation signal input, measurement mode, rotation direction
Update timeMeasurement value: 1s/10s/external
Condition display: 0.5s
Torque measurementDisplayed digit number (with polarity)TH type: 4/5-digit (selectable), other than TH type: 4-digit
Measurement unitmN· m, N· m, kN· m
Measurement accuracyDepends on the torque detector connected
Compensation range
of torque factor
0.8000 to 1.2000
N-0*1 compensation5 points for each direction of CW/CCW
Other functionsZero setting, analog output calibration
Analog outputVoltage (Signal commons of torque output and rotation speed output are isolated from main circuit of TS-2800. However, both commons are connected each other.)
Range0 to ±10V / F.S.
F.S. settingSelectable from 100%, 66.7%, 50%, 33.3%, 25%, 20% (percentage to the torque capacity)
ResponseTH type: 500ms, 63ms, 16ms, 1.6ms (standard) 0.8ms, 0.4ms, 0.16ms (*2 added optionally)

Other than TH type: 500ms and 63ms (standard) 63ms and 16ms (*3 selectable either of pair optionally)

Low pass filterAvailable only TH type: 50Hz, 100Hz, 500Hz, 1kHz, 5kHz (*2 added optionally)
Output accuracy±0.1 %/F.S. or ±0.2 %/F.S.(depending on the accuracy of detector)
Rotation speed measurement sectionNumber of display digit5 digits (0 to 99,999 r/min)
Measurement accuracy±0.02%/F.S ±1 count (10 Hz or more, average every second)
F.S range200 to 100,000 r/min (Can be set every 1 r/min)
Pulsation range of rotation detector1 to 9999 P/R (Can be set every 1 P/R)
Analog outputVoltage (Signal commons of torque output and rotation speed output are isolated from main circuit of TS-2800. However, both commons are connected each other.)
Output range0 to 10 V / F.S.
ResponseTH type:0.16 ms, other than TH type:63 ms
Output accuracy±0.1 %/F.S. or ±0.2 %/F.S. (when SIG2 is used as rotation signal)
Rotation pulse output *4Output the pulse signal from rotation sensor terminal
Output levelLo: +0.5 V or less, Hi: +5±0.5 V
External interfaceRemote controlInput itemCW/CCW changeover, display/output clear, display/BCD trigger
Output itemTrigger output (synchronous updating), measurement ready
Input formatNon-voltage contact, or logic input( Lo:0 to 1.4 V, Hi:3 to 5.25 V)
Output formatNon-voltage contact output(PhotoMOS relay output)
Applicable connectorFK-MC0,5/8-ST-2,5 (Made by Phoenix Contact) provided as standard
RS-232CReadout of measurement value, setting zero value, setting N-0 value, and setting/readout of other functions
Baud rate9600 bps (fixed)
Applicable cableAX-5022A (2m)
General specificationPower supply voltageAC 100 to 240 V, 50/60 Hz
Operating temperature range0 to +40 °C
WeightApprox. 2 kg
                                   *1: N-0:rotation dependence at torque zero. It occurs due to detector characteristics, torque loss between torque detector and measurement object etc.
                                   *2 to *4: Available when the option for each function is installed.

                            TH type: Phase difference method using electromagnetic induction theory

Optional function

TS-0281 High-speed response output function for TH series*2Refer to (*2) above for the specification.
TS-0282 Time constant change function for DD series*3Refer to (*3) above for the specification.
TS-0283 BCD output functionOutput dataTorque(with polarity, without decimal point, 5-digit), rotation speed (5-digit), print command
Input dataHold, busy
Output methodPositive logic open collector
Input methodNon-voltage contact input, or logic input (Lo:1.4 V or less, Hi:3 to 5.25 V)
Applicable
connector
DX40-50P, or DX30-50P (Made by HIROSE ELECTRIC. CO.LTD)
TS-0284 Rotation pulse output function*4Refer to (*4) above for the specification.
                                            *2 to *4: Available when the option for each function is installed.

Torque Detector DSTP series
For high rigidity

The DSTP series is designed as the large capacity type torque detector which is able to perform the torque measurement from standstill axis to a high speed rotation. Four types of large capacity products are available

Feature

  • •  Four types of large capacity units are available.
  • •  Excellent at overload resistance
  • •  Wide measurement range: Up to approx. 180% of rated torque continuous measurement is applicable
  • •  Wide rotation speed range: From stop state (0 r/min) to high speed rotation state can be measured with one unit.

Specifications


Model

 Rated torque

Resolution

Rated rotational speedInertia MomentSpring Constant
NmmN · mr/minkgcm2N · m/rad
DSTP-5005,0001,0004,0003.74 x 10-24.81 x 105
DSTP-100010,00010,0003,0009.69 x 10-29.71 x 105
DSTP-200020,00010,0002,0003.32 x 10-13.04 x 106
DSTP-500050,00010,0001,5008.53 x 10-17.06 x 106

                                1 N·m = 0.1019716 kgfm

General Specifications (common among models)


Measurement Accuracy±0.2 % F.S   (when combined with the TS-2800/3200A(N-0 correction))
Temperature Effect+0.03 %/F.S./ ℃
Applicabel Revolution detectorMP-981 (option)
Operating Temperature Range0 to +50 °C (DSTP-500/1000)
0 to +45 ℃ (DSTP-2000/5000/10000)
Storing Temperature Range-20 ℃ to +60 ℃
Humidity Range85 % or less
Vibration Resistance50 m/s2 or less
Applicable Connector12P2B
Power SupplyAC 3-phase 200 V 50/60 Hz
AccessoryPower cable (5 m), Torque signal cable (5 m)
Option· Torque detector
· Gear for rotation detector
· Rotation signal cable

Torque Detector SS series
Small / Medium Capacity Type

The SS series torque detector suits to wide variety of torque measurement application, including performance test of motors, pumps, compressors, blowers, turbines and gears. High rigidity results from the unitized cast-casing structure and SS series torque detector can be handled easily as being free from parts replacement on treatment of maintenance, comparing to other type of torque detector such as strain gauges, with non contact signal detection on the detector. 13 models in the series can be provided and chosen among them according to requirement in torque capacity.

Feature

  • • In-stock items, cost effective type
  • • Wide measurement range: Up to approx. 180% of rated torque continuous measurement is applicable
  • • Excellent at overload resistance

Specifications


Model

 Rated torque

Resolution

Rated rotational speed (r/min)Inertia Moment (kgm2)Spring Constant (Nm/rad)Weight (kg)
NmkgfcmmNmkgfcm
SS-0020.20.020.10.0016,0004.25 x 10-51.67 x 105
SS-0050.50.050.10.0016,0004.25 x 10-54.12 x 105
SS-01010.110.016,0004.25 x 10-58.24 x 105
SS-02020.210.016,0004.25 x 10-51.67 x 1025
SS-05050.510.016,0004.25 x 10-54.12 x 1025
SS-100101100.18,0005.00 x 10-57.75 x 1025.5
SS-200202100.18,0005.00 x 10-51.57 x 1035.5
SS-500505100.16,0001.30 x 10-36.18 x 10314
SS-1011001010016,0001.30 x 10-31.27 x 10414
SS-2012002010016,0001.45 x 10-32.54 x 10415
SS-5015005010016,0001.50 x 10-36.18 x 10415
SS-10210001001000105,0005.00 x 10-31.67 x 10523
SS-20220002001000105,0005.25 x 10-33.43 x 10523
1 N·m=0.1019716 kgfm

General Specifications (common among models)

Measurement Accuracy±0.2 % F.S   (when combined with the TS-2800/3200A (N-0 correction))
Temperature Effect+0.03 % F.S./℃
Applicable Revolution detectorMP-981 (option)
Operating Temperature Range0 to +40°C
Storage temperature range−20 ℃ to +60 ℃
Humidity Range85 % or less
Vibration Resistance50 m/s2 or less
Applicable ConnectorTRC116-12A10-7M10.5
Gear Teeth for Rotation DetectorStandard accessory(60 P/R)
Power Supply100 VAC 50/60 Hz,
SS-002 to 200:35 VA,
SS-500 to 202:50 VA
AccessoryPower cable (2.4 m), Torque signal cable (5 m), Shaft-end key(Only for SS-100 to 202)
Option·MP-981 Magneto-electric rotation detector
·MX-8105 Rotation Signal Cable
·SS-0004 External control of the rotation direction
(↑The rotation direction of the motor with a detector can be switched externally. Only wiring, not including selection switch.)

Torque Detector MD series
Micro Capacity Type

The MD series torque detector is designed to measure the torque output from compact & precision type motors used in the electric & electronics industry, the automotive industries and so on, featuring outstanding low inertia and low starting torque. With the phase differential system, it can realize low capacity torque measurement as small as 0.001mNm.

Made to Order

Feature

  • • High accurate detection of micro capacity torque (mN·m)
  • • Focused on measurement: Low moment of inertia and small starting torque
  • • Wide measurement range: From stationary condition (0 r/min) to high rotation speed can be measured with one unit.
  • • Applicable to new rotation detector (MD-0110 series option)

Specifications


Model

 Rated torque

Resolution

Rated rotational
speed
Allowable
range
Inertia
Moment
Spring
Constant
Weight
mNm
mNm
r/min
r/min
kgm2
Nm/rad
kg
MD-201C
2
0.001
10,000
0 to 10,000
1.9 × 10-7
8.24 x 10-2
1.5
MD-501C
5
0.001
10,000
0 to 20,000
1.9 × 10-7
2.06 x 10-1
1.5
MD-102C
10
0.01
10,000
0 to 20,000
1.9 × 10-7
4.12 x 10-1
1.5
MD-202C
20
0.01
10,000
0 to 20,000
1.9 × 10-7
8.24 x 10-1
1.5

                                * Revolution speed range can be changed up to the allowable range.

                                            * The MD series torque detectors below are replaced by the following TH-3000 series.

Specifications


Measurement accuracy±0.2 % / F.S.(when N-0 correction combined with the TS-2800/3200A)
Temperature effect+0.03 % /F.S. / ℃
Applicable detectorMD-0110 series(option)
Operating temperature range0 to+50 ℃
Storage temperature range−20 ℃ to +60 ℃
Operating humidity range85 %  or less
Registance to vibration50 m/s2 or less
Connection methodCable side connector TRC116-12A10-7M10.5
Power requirementAC 100 V 50/60 Hz,  10 VA
AccessoryPower cable(2.4 m), torque signal cable(5 m)
                                Option·Rotation detector MD-0110 series (120 P/R) for MD type
·MX-8105 cable for MD type
·MD-0004 external control of rotation derection
< ↑ The rotation direction of the motor with a detector can be switched externally. Only wiring, not including selection switch.>

Micro capacity type high-speed rotation torque detector TH-3000/3000H Series

TH-3000 series is a torque detector designed for very low torque (less than 2 N· m) with high response and high accuracy. Two types are available depending on your applications.



The TH-3000 series is standard type, and the TH-3000H is for high speed rotation.

It enables accurate torque detection from small precise machines and other machineries with high resolution. Excellent at response, torque ripple produced in actual rotation speed can also be measured.



The TH-3000 series works for development of a small rotating object which is required energy efficiency and noise-free. Selectable from rated torque 0.05 N· m, 0.2 N· m, 0.5 N· m or 2 N· m.

TH-3000/3000H series is used in combination with the TS-2800 Digital Torque Meter.

Features

· High speed response
Up to 5 kHz of torque variation can be detected. (*1)

· Available up to 25,000 r/min of rotation speed. Best suited to performance test of small motors
TH-3000H series: High-speed type, 25,000 r/min of rated torque
TH-3000 series: Standard type, 15,000 r/min of rated torque

· High accuracy
Measurement in high accuracy of ±0.2 %/F.S. (*2)

· Overload-resistant mechanism
The original overload-resistant mechanism is adopted to protect the high sensitive detector from overload torque. It can withstand against up to 3 Nm of overload torque. (*3)

· Line driver output having great noise resistance
Line driver output with strong noise immunity. Suitable for in-line use.

· Matching is not necessary at changing cable length
The matching is not required when the cable length is changed. Up to 50 m of cable can be used.

· Compatible size with MD series
Easy replacement from Ono Sokki’s long selling torque detector MD series. It has same outer dimensions to the TH-3000/3000H series.

· Easy coupling
Easier to mount coupling because the shaft length to be used has become longer than the previous models.

· High durability
Non-contact detection. No moving part brings ease of maintenance and less trouble.
(*1)Due to output characteristics of torque meter. The TH-0511 High-speed analog output function (option of the TH-5100 torque meter) is required. The value can be restricted by torsional resonance of equipments.
(*2)Static calibration (average per second)
(*3)The value is maximum overload that the TH-3000 series can withstand when an instantaneous torque is applied, not the maximum value to be used continuously.

Application example

Testing torque characteristics of small motors (T-N characteristic, torque ripple, cogging torque, pull-in/pull-out torque)
Measuring torque ripple at actually used rotation speed.
Measuring high precision motor efficiency
Measuring transient torque at start-up and stop
Measuring constant/changing torque of driving sections such as motors or rollers in precision equipments. (O.A. equipment or camera etc.)

Application

Overview Specification
Model nameTH-3502/3502HTH-3103/3103HTH-3203/3203H
Rated torque0.05 N•m0.1 N•m0.2 N•m
Critical (Breakdown) torque (*4)(*5)180 % of rated torque
Linearity (1 seconds average, static calibration)±0.2 %/F.S.
Temperature effect at zero point±0.02 %/F.S./°C
Temperature effect on the sensitivity±0.02 %/F.S./°C
Rated rotational speedTH-3000 series:15,000 r/min
TH-3000H series:25,000 r/min
Rotation detector (sold separately)MD-0115 (number of pulses:120 P/R, output:square wave (0/+5 V))
Signal outputSquare wave with phase difference, line driver output
Inertia moment2.37 × 10-6 kgm2
Spring constant2.06 N•m/rad4.12 N•m/rad7.63 N•m/rad
Outer Dimensions (main unit)80(W) × 90(D) × 110(H) mm
Outer Dimensions (shaft)Shaft length:110 mm, shaft diameter:φ5 (D-cut shaft)
Weight0.83 kg0.83 kg0.83 kg
Operating temperature /humidity range0 to +40 °C,
85 %RH or less (with no condensation)
Storage temperature range-20 to +60 °C
Power supplySupplied from the torque meter
AccessoryInstruction manual, calibration chart
Applicable torque meterTS-2800 (*6)
Option
  • Rotation detector (MD-0115)

  • Torque signal cable (TH-0100 series)

Model nameLength(m)
TH-0105

5

TH-0110

10

TH-0120

20

  • Rotation signal cable (MX-8100 series)

Model nameLength(m)
MX-8105

5

MX-8110

10

MX-8120

20



Model nameTH-3503/3503HTH-3104/3104HTH-3204/3204H
Rated torque0.5 N•m1 N•m2 N•m
Critical (Breakdown) torque (*4)(*5)400 % of rated torque
Linearity (1 seconds average, static calibration)±0.2 %/F.S.
Temperature effect at zero point±0.02 %/F.S./°C
Temperature effect on the sensitivity±0.02 %/F.S./°C
Rated rotational speedTH-3000 series:15,000 r/min
TH-3000H series:25,000 r/min
Rotation detector (sold separately)MD-0118 (number of pulses:120 P/R, output:square wave (0/+5 V))
Signal outputSquare wave with phase difference, line driver output
Inertia moment7 × 1
